57
HCD-GP6V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
R825 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R830 1-216-833-11 METAL CHIP 10K 5% 1/16W
R831 1-216-833-11 METAL CHIP 10K 5% 1/16W
R832 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R833 1-216-808-11 METAL CHIP 82 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
R844 1-216-809-11 METAL CHIP 100 5% 1/16W
R849 1-216-809-11 METAL CHIP 100 5% 1/16W
R850 1-216-864-11 METAL CHIP 0 5% 1/16W
R851 1-216-864-11 METAL CHIP 0 5% 1/16W
R852 1-216-864-11 METAL CHIP 0 5% 1/16W
R853 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R901 1-218-285-11 METAL CHIP 75 5% 1/10W
R902 1-216-813-11 METAL CHIP 220 5% 1/16W
R903 1-216-864-11 METAL CHIP 0 5% 1/16W
R906 1-216-821-11 METAL CHIP 1K 5% 1/16W
R909 1-216-821-11 METAL CHIP 1K 5% 1/16W
R921 1-216-809-11 METAL CHIP 100 5% 1/16W
R922 1-216-809-11 METAL CHIP 100 5% 1/16W
R923 1-216-809-11 METAL CHIP 100 5% 1/16W
R925 1-216-864-11 METAL CHIP 0 5% 1/16W
R926 1-216-864-11 METAL CHIP 0 5% 1/16W
R927 1-216-864-11 METAL CHIP 0 5% 1/16W
R930 1-216-809-11 METAL CHIP 100 5% 1/16W
R931 1-216-809-11 METAL CHIP 100 5% 1/16W
R932 1-216-809-11 METAL CHIP 100 5% 1/16W
R933 1-216-809-11 METAL CHIP 100 5% 1/16W
R934 1-216-809-11 METAL CHIP 100 5% 1/16W
R935 1-216-809-11 METAL CHIP 100 5% 1/16W
R936 1-216-809-11 METAL CHIP 100 5% 1/16W
R937 1-216-809-11 METAL CHIP 100 5% 1/16W
R938 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R939 1-216-847-11 METAL CHIP 150K 5% 1/16W
R940 1-216-843-11 METAL CHIP 68K 5% 1/16W
R941 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R942 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R943 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R944 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R945 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R946 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R947 1-216-809-11 METAL CHIP 100 5% 1/16W
R951 1-216-864-11 METAL CHIP 0 5% 1/16W
< VIBRATOR >
X801 1-795-630-11 VIBRATOR, CRYSTAL (27 MHz)
************************************************************
V-OUT BOARD
************
< CAPACITOR >
C211 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C212 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C213 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN202 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB203 1-412-473-21 INDUCTOR (SMALL TYPE)
FB204 1-412-473-21 INDUCTOR (SMALL TYPE)
FB205 not supplied
< JACK >
J205 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< SWITCH >
S201 not supplied
************************************************************
MISCELLANEOUS
**************
3 1-693-620-11 TUNER (FM/AM)
73 1-796-351-51 MECHANISM, SIGNAL CASSETTE
0 105 1-765-558-11 CORD, POWER
202 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0 203 A-4735-189-A BU-30(61)ASSY
M901 A-4735-337-A MOTOR (LD) ASSY
VCD V-OUT
