Sony HCD-MG110 - Printed Wiring Boards - AMP Section

HCD-MG110/MG310AV
4040
MAIN AMP BOARD
E
E
E
E
E
E
E
E
J
MAIN BOARD
CN317
(MG310AV)
E
E
E
(MG310AV)
E
E
E
E
(MG310AV)
E
(MG310AV)
1-680-801-
12
(12)
H
MAIN BOARD
CN309
P
FUSE BOARD
CNP905
R
POWER BOARD
CNP902
(MG110) (MG310AV)
E
–
+
–
+
–
+
L
R
FRONT SPEKAER
IMPEDANCE
USE 8Ω
CENTER
IMPEDANCE
USE 8Ω
–
+
–
+
L
R
REAR
IMPEDANCE
USE 8Ω
SURROUND
SPEKAER
(MG310AV)
PHONE
64
2
1
53
KEY BOARD
INPUT
J801
3
4
5
6
1
2
(FRONT VIEW)
H/P
BOARD
1-680-796-
11
(11)
M
MAIN BOARD
CN310
B
C
D
E
F
G
H
I
A
1 2 3 4 5 6 7 8 9 10 11
E
E
E
E
E
E
E
E
E
E
E
11
(11)
21
(21)
(AUS)(US, CND, MX)
R529
(AUS)
R516
21
(21)
(MG310AV)(MG110)
D503
R522
R518
(AUS)
(AUS)
(AUS)
7-18. PRINTED WIRING BOARDS – AMP Section – • See page 26 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D501 H-8
D502 C-8
D503 H-11
D504 F-8
D507 G-9
D508 C-9
D509 E-6
D510 E-11
D511 D-9
D512 D-11
D513 D-11
D601 G-7
D602 F-7
D603 G-7
IC501 D-5
IC602 G-5
Q501 C-6
Q502 G-11
Q503 H-9
Q504 E-10
Q505 D-11
Q506 D-6
Q507 E-7
Q508 D-11
Q509 G-10
Q510 F-10
Q513 F-10
Q514 F-11
Q515 E-10
Q516 D-11
Q517 E-5
Q518 C-6
Q519 C-10
Q520 C-10
Q521 D-11
Q522 F-11
Q523 F-11
Q524 F-11
Q601 H-10
Q602 H-6
Q603 E-5
Q604 G-7
Q605 F-6
Q606 H-7
(Page 38)
(Page 38)
(Page 46)
(Page 46)
(Page 38)
Ver 1.3
