Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
60
HCD-MG110/MG310AV
CD CD LED CONTROL
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R109 1-216-857-11 METAL CHIP 1M 5% 1/16W
R111 1-216-846-11 METAL CHIP 120K 5% 1/16W
R114 1-218-745-11 RES-CHIP 160K 5% 1/16W
R116 1-216-797-11 METAL CHIP 10 5% 1/16W
R117 1-216-821-11 METAL CHIP 1K 5% 1/16W
R118 1-216-809-11 METAL CHIP 100 5% 1/16W
R119 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R120 1-216-835-11 METAL CHIP 15K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-845-11 METAL CHIP 100K 5% 1/16W
R131 1-216-813-11 METAL CHIP 220 5% 1/16W
R143 1-216-836-11 METAL CHIP 18K 5% 1/16W
R144 1-216-836-11 METAL CHIP 18K 5% 1/16W
R147 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R148 1-216-797-11 METAL CHIP 10 5% 1/16W
R149 1-216-797-11 METAL CHIP 10 5% 1/16W
R150 1-216-833-11 METAL CHIP 10K 5% 1/16W
R151 1-216-845-11 METAL CHIP 100K 5% 1/16W
R158 1-216-837-11 METAL CHIP 22K 5% 1/16W
R159 1-216-837-11 METAL CHIP 22K 5% 1/16W
R162 1-216-847-11 METAL CHIP 150K 5% 1/16W
R171 1-216-837-11 METAL CHIP 22K 5% 1/16W
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R173 1-216-837-11 METAL CHIP 22K 5% 1/16W
R181 1-216-837-11 METAL CHIP 22K 5% 1/16W
R182 1-216-837-11 METAL CHIP 22K 5% 1/16W
R183 1-216-837-11 METAL CHIP 22K 5% 1/16W
R190 1-216-813-11 METAL CHIP 220 5% 1/16W
R191 1-216-839-11 METAL CHIP 33K 5% 1/16W
R192 1-216-839-11 METAL CHIP 33K 5% 1/16W
R193 1-216-846-11 METAL CHIP 120K 5% 1/16W
R194 1-216-845-11 METAL CHIP 100K 5% 1/16W
R195 1-216-853-11 METAL CHIP 470K 5% 1/16W
R196 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R197 1-216-821-11 METAL CHIP 1K 5% 1/16W
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X101 1-767-226-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
1-680-795-11 CD LED BOARD (US, CND, MX)
1-680-795-21 CD LED BOARD (AUS)
*************
< CONNECTOR >
CN803 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< LED >
D781 8-719-058-64 LED SEL5823A-TP15 (DISC ILLUMINATION)
D782 8-719-058-03 LED SEL5423E-TP15 (DISC ILLUMINATION)
< RESISTOR >
R781 1-216-805-11 METAL CHIP 47 5% 1/16W
**************************************************************
A-4476-367-A CONTROL BOARD, COMPLETE
*************************
< CONNECTOR >
CN708 1-784-734-11 CONNECTOR, FFC 12P
< LED >
D708 8-719-052-06 LED SLR-342MGT32 (PRESET EQ)
D736 8-719-060-44 LED SLR-342VRT32 (I/1)
< TRANSISTOR >
Q718 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R725 1-216-813-11 METAL CHIP 220 5% 1/16W
R736 1-216-821-11 METAL CHIP 1K 5% 1/16W
R750 1-216-839-11 METAL CHIP 33K 5% 1/16W
R751 1-216-833-11 METAL CHIP 10K 5% 1/16W
R752 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R753 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R754 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R755 1-216-821-11 METAL CHIP 1K 5% 1/16W
R756 1-216-819-11 METAL CHIP 680 5% 1/16W
R760 1-216-839-11 METAL CHIP 33K 5% 1/16W
R761 1-216-833-11 METAL CHIP 10K 5% 1/16W
R762 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R763 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R764 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R765 1-216-821-11 METAL CHIP 1K 5% 1/16W
R766 1-216-819-11 METAL CHIP 680 5% 1/16W
R771 1-216-833-11 METAL CHIP 10K 5% 1/16W
R772 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R773 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R774 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R775 1-216-821-11 METAL CHIP 1K 5% 1/16W
R776 1-216-819-11 METAL CHIP 680 5% 1/16W
< ROTARY ENCODER >
RV701 1-473-392-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
S700 1-762-196-21 SWITCH, TACT (I/1)
S750 1-762-196-21 SWITCH, TACT (SURROUND MODE)
S751 1-762-196-21 SWITCH, TACT (PRESET EQ)
S752 1-762-196-21 SWITCH, TACT (ENTER)
S753 1-762-196-21 SWITCH, TACT (– . )
S754 1-762-196-21 SWITCH, TACT (M +)
S755 1-762-196-21 SWITCH, TACT(X PAUSE)
S756 1-762-196-21 SWITCH, TACT (x)
S757 1-762-196-21 SWITCH, TACT (n N)
S760 1-762-196-21 SWITCH, TACT (TIMER SELECT)
S761 1-762-196-21 SWITCH, TACT (TIMER SET)
Ver 1.3
