Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
HCD-MG110/MG310AV
1-680-796-11 H/P BOARD (US, CND, MX)
1-680-796-21 H/P BOARD (AUS)
**********
< JACK >
J503 1-815-629-11 JACK (SMALL TYPE) (DIA.3.5) (PHONE)
J801 1-815-575-11 CONNECTOR, DIN 6P (KEYBOARD)
< COIL >
L801 1-410-517-11 INDUCTOR 47uH
**************************************************************
1-680-797-11 L.T MOTOR BOARD (US, CND, MX)
1-680-797-21 L.T MOTOR BOARD (AUS)
****************
**************************************************************
1-680-798-11 LOAD SW BOARD (US, CND, MX)
1-680-798-21 LOAD SW BOARD (AUS)
***************
< SWITCH >
S842 1-786-154-11 SWITCH, LEVER SLIDE (LOAD)
**************************************************************
A-4476-388-A MAIN BOARD, COMPLETE
(MG310AV: US, CND)
A-4476-390-A MAIN BOARD, COMPLETE (MG110: US, CND)
A-4726-728-A MAIN BOARD, COMPLETE (AUS)
A-4730-460-A MAIN BOARD, COMPLETE (MG110: MX)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C100 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-126-960-11 ELECT 1uF 20% 50V
C104 1-126-960-11 ELECT 1uF 20% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C107 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C108 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C110 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C111 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C112 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C113 1-126-963-11 ELECT 4.7uF 20% 50V
C114 1-126-963-11 ELECT 4.7uF 20% 50V
(MG310AV)
C115 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C116 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C117 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C118 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C119 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C120 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C121 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C122 1-126-963-11 ELECT 4.7uF 20% 50V
C123 1-126-963-11 ELECT 4.7uF 20% 50V
C124 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
(US, CND, MX)
C124 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(AUS)
C130 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C131 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C141 1-136-165-00 FILM 0.1uF 5% 50V
C142 1-136-165-00 FILM 0.1uF 5% 50V
C143 1-126-964-11 ELECT 10uF 20% 50V
C144 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C145 1-126-961-11 ELECT 2.2uF 20% 50V
C150 1-126-963-11 ELECT 4.7uF 20% 50V
(MG110)
C172 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C176 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(MG310AV)
C200 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C201 1-126-960-11 ELECT 1uF 20% 50V
C202 1-126-960-11 ELECT 1uF 20% 50V
C203 1-126-960-11 ELECT 1uF 20% 50V
C204 1-126-960-11 ELECT 1uF 20% 50V
C205 1-126-960-11 ELECT 1uF 20% 50V
C206 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C207 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C208 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C210 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C211 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C212 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C213 1-126-963-11 ELECT 4.7uF 20% 50V
C214 1-126-963-11 ELECT 4.7uF 20% 50V
(MG310AV)
C215 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C216 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C217 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C218 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C219 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C220 1-126-961-11 ELECT 2.2uF 20% 50V
(MG310AV)
C221 1-126-964-11 ELECT 10uF 20% 50V
(MG310AV)
C222 1-126-963-11 ELECT 4.7uF 20% 50V
C223 1-126-963-11 ELECT 4.7uF 20% 50V
C224 1-104-509-11 CERAMIC CHIP 0.018uF 10% 16V
(US, CND, MX)
C224 1-162-970-11 CERMIC CHIP 0.01uF 10% 25V
(AUS)
H/P L.T MOTOR LOAD SW MAIN
Ver 1.3
