Sony HCD-MG110 - Page 68

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
68
HCD-MG110/MG310AV
R382 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R383 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R384 1-216-845-11 METAL CHIP 100K 5% 1/16W
R385 1-216-845-11 METAL CHIP 100K 5% 1/16W
R386 1-216-841-11 METAL CHIP 47K 5% 1/16W
R387 1-216-843-11 METAL CHIP 68K 5% 1/16W
R388 1-216-843-11 METAL CHIP 68K 5% 1/16W
R389 1-216-841-11 METAL CHIP 47K 5% 1/16W
R390 1-216-841-11 METAL CHIP 47K 5% 1/16W
R391 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R392 1-216-825-11 METAL CHEP 2.2K 5% 1/16W
(AUS)
R393 1-216-845-11 METAL CHIP 100K 5% 1/16W
R395 1-216-821-11 METAL CHIP 1K 5% 1/16W
R396 1-216-845-11 METAL CHIP 100K 5% 1/16W
R397 1-216-857-11 METAL CHIP 1M 5% 1/16W
R399 1-216-809-11 METAL CHIP 100 5% 1/16W
R801 1-216-833-11 METAL CHIP 10K 5% 1/16W
R802 1-216-809-11 METAL CHIP 100 5% 1/16W
R803 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R804 1-216-841-11 METAL CHIP 47K 5% 1/16W
R805 1-216-841-11 METAL CHIP 47K 5% 1/16W
R806 1-216-833-11 METAL CHIP 10K 5% 1/16W
R807 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R808 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R809 1-216-841-11 METAL CHIP 47K 5% 1/16W
R810 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R811 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R812 1-216-813-11 METAL CHIP 220 5% 1/16W
R813 1-216-811-11 METAL CHIP 150 5% 1/16W
R814 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(MG310AV)
R815 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R816 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MX)
R816 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(US, CND)
R817 1-216-821-11 METAL CHIP 1K 5% 1/16W
R818 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R819 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R820 1-216-845-11 METAL CHIP 100K 5% 1/16W
R821 1-216-821-11 METAL CHIP 1K 5% 1/16W
R822 1-216-821-11 METAL CHIP 1K 5% 1/16W
R823 1-216-821-11 METAL CHIP 1K 5% 1/16W
R824 1-216-821-11 METAL CHIP 1K 5% 1/16W
R825 1-216-821-11 METAL CHIP 1K 5% 1/16W
R826 1-216-821-11 METAL CHIP 1K 5% 1/16W
R827 1-216-845-11 METAL CHIP 100K 5% 1/16W
R828 1-216-849-11 METAL CHIP 220K 5% 1/16W
R829 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R830 1-216-821-11 METAL CHIP 1K 5% 1/16W
R831 1-216-809-11 METAL CHIP 100 5% 1/16W
R832 1-216-821-11 METAL CHIP 1K 5% 1/16W
R833 1-216-821-11 METAL CHIP 1K 5% 1/16W
R834 1-216-821-11 METAL CHIP 1K 5% 1/16W
R835 1-216-821-11 METAL CHIP 1K 5% 1/16W
R836 1-216-821-11 METAL CHIP 1K 5% 1/16W
R881 1-249-382-11 CARBON 1.2 5% 1/6W
R882 1-249-382-11 CARBON 1.2 5% 1/6W
R883 1-216-833-11 METAL CHIP 10K 5% 1/16W
R884 1-216-833-11 METAL CHIP 10K 5% 1/16W
R885 1-216-833-11 METAL CHIP 10K 5% 1/16W
R886 1-216-845-11 METAL CHIP 100K 5% 1/16W
R887 1-216-845-11 METAL CHIP 100K 5% 1/16W
R971 1-216-813-11 METAL CHIP 220 5% 1/16W
R972 1-216-813-11 METAL CHIP 220 5% 1/16W
R973 1-216-833-11 METAL CHIP 10K 5% 1/16W
R974 1-216-845-11 METAL CHIP 100K 5% 1/16W
R975 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R1325 1-216-845-11 METAL CHIP 100K 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-241-765-11 RES, ADJ, CARBON 22K
< VIBRATOR >
X801 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
**************************************************************
A-4476-384-A MAIN AMP BOARD, COMPLETE
(MG310AV: US, CND)
A-4476-386-A MAIN AMP BOARD, COMPLETE (MG110)
A-4726-722-A MAIN AMP BOARD, COMPLETE (AUS)
*************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C500 1-126-947-11 ELECT 47uF 20% 10V
C501 1-104-665-11 ELECT 100uF 20% 10V
C502 1-104-665-11 ELECT 100uF 20% 10V
C503 1-126-953-11 ELECT 2200uF 20% 35V
(MG310AV)
C504 1-126-953-11 ELECT 2200uF 20% 35V
(MG310AV)
C505 1-130-495-00 MYLAR 0.1uF 5% 50V
C506 1-130-495-00 MYLAR 0.1uF 5% 50V
C507 1-130-495-00 MYLAR 0.1uF 5% 50V
C508 1-130-495-00 MYLAR 0.1uF 5% 50V
C509 1-126-961-11 ELECT 2.2uF 20% 50V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MG310AV)
C511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(MG310AV)
C512 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C513 1-128-550-11 ELECT 2200uF 20% 50V
C514 1-128-550-11 ELECT 2200uF 20% 50V
C515 1-126-960-11 ELECT 1uF 20% 50V
C517 1-126-968-11 ELECT 100uF 20% 50V
C518 1-126-968-11 ELECT 100uF 20% 50V
C519 1-104-665-11 ELECT 100uF 20% 10V
C520 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C521 1-126-967-11 ELECT 47uF 20% 50V
C522 1-126-967-11 ELECT 47uF 20% 50V
C523 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C524 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C525 1-164-156-11 CERAMIC CHIP 0.1uF 25V
MAIN MAIN AMP
Ver 1.3
