11
HCD-NXM2D
3-7. FRONT AMP BOARD
3
two
screws
(sumitite (B3)
)
4
two
screws
(sumitite (B3))
qs
FRONT AMP board
5
connector
(CN502)
7
screw
(+BVTP 3
X8
)
6
screw
(+BVTP 3
X8
)
8
two
screws
(+BVTP 3
X8
)
9
bracket
q;
two
screws
(+BVTP 3
X8
)
qa
bracket
1
screw
(+BVTP 3
X8
)
2
sp out board
