Sony HCD-NXM2D - Tape Mechanism Deck; Panel Board

12
HCD-NXM2D
3-8. TAPE MECHANISM DECK
3-9. PANEL BOARD
1 four screws
(+BVTP 2.6X8
)
2 screw
(+BVTP 2.6X8)
3 screw
(+BVTP 2.6X8)
4 bracket (main)
5 screw
(+BVTP 2.6X8)
6 three screws
(+BVTP 2.6X8)
7 PANEL board
1
2
3
two screws
(+P 2.6X3)
4 two screws
(+BV (B3))
5 tape mechanism dec
k
