HCD-NXM2D
3-14. BASE UNIT (DVBU60)
3-15. RF BOARD
1
two floating
screw
(+PTPWH2.6)
2
base unit (DVBU60)
1
screw
(+BTP 2.6
X6
)
2
screw
(+BTP 2.6
X6
)
4
CNP101
3
RF board
