13
HCD-NXM2D
3-10. VIDEO BOARD
3-11. DMB07 BOARD, DVD MECHANISM DECK (CDM81A-DVBU60)
1
CNP1101
2
screw
(+BVTP 3
X8
)
3
screw
(+BVTP 3
X8
)
4
VIDEO boar
d
1
CNP501
2
CNP105
3
CNP107
4
two
screws
(+BVTP 3
X8
)
5
screw
(+BVTP 3
X8
)
6
screw
(+BVTP 3
X8
)
7
DMB07 board
8
two
screws
(+BVTP 3
X8
)
9
screw
(+BVTP 3
X8
)
0
screw
(+BVTP 3
X8
)
qa
screw
(+BVTP 3
X8
)
qs
DVD mechanism dec
k
(CDM81A-DVBU60)
