Sony HCD-NXM2D - ELECTRICAL PARTS LIST; Disc SW Board Components

83
HCD-NXM2D
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
E2 : 120 V AC Area in E model
E3 : 240 V AC Area in E model
E15 : Iran model
EA : Saudi Arabia model
SP : Singapore model
MY : Malaysia model
TH : Thai model
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board.
DISC SW BOARD
*************
< CAPACITOR >
C1001 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1002 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1003 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1004 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1005 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1009 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< DIODE >
D1001 6-500-327-01 DIODE SEL5E23C-STP15 (DISC 1)
D1002 6-500-327-01 DIODE SEL5E23C-STP15 (DISC 2)
D1003 6-500-327-01 DIODE SEL5E23C-STP15 (DISC 3)
D1004 6-500-327-01 DIODE SEL5E23C-STP15 (DISC 4)
D1005 6-500-327-01 DIODE SEL5E23C-STP15 (DISC 5)
< TRANSISTOR >
Q1001 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1002 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1003 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1004 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1005 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1001 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1002 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1004 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1005 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1006 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1007 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1008 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1009 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1010 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1011 1-216-813-11 METAL CHIP 220 5% 1/10W
R1012 1-216-815-11 METAL CHIP 330 5% 1/10W
R1013 1-216-817-11 METAL CHIP 470 5% 1/10W
R1014 1-216-819-11 METAL CHIP 680 5% 1/10W
< SWITCH >
S1001 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S1002 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S1003 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S1004 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S1005 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
************************************************************
A-1063-666-A DMB07 PC BOARD ASSY (TH)
A-4752-550-A DMB07 PC BOARD ASSY (EXCEPT TH)
******************
< CAPACITOR >
C101 1-126-246-11 ELECT CHIP 220uF 20% 4V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C201 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C202 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C203 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C204 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C205 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C213 1-126-209-11 ELECT CHIP 100uF 20% 4V
C214 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C215 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C216 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C218 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C220 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C226 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C227 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C229 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C230 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C231 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C232 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C233 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C234 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C235 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C236 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C237 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C238 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C239 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C240 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C241 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C242 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
DMB07
DISC SW
