17
HCD-NXM2D
SECTION 4
TEST MODE
[Change-over of AM Tuner Step between 9 kHz and 10 kHz]
•A step of AM channels can be changed over between 9 kHz
and 10 kHz.
Procedure:
1. Press
?/1
button to turn the set ON.
2. Select the function “TUNER”, and press [TUNER/BAND]
button to select the BAND “AM”.
3. Press
?/1
button to turn the set OFF.
4. Press x button continuously, then press
?/1
button. The
set will POWER on automatically, and the display of
fluorescent indicator tube changes to “AM 9 kHz step” or “AM
10 kHz step”, and thus the channel step is changed over.
[Cold Reset]
• The cold reset clears all data including preset data stored in
the RAM to initial conditions. Execute this mode when
returning the set to the customer.
Procedure:
1.
Press x button continuously, then press [DIMMER]
and
?/1
buttons
.
[Switching MD/VIDEO Functions]
Procedure:
1. Press the
?/1
button to turn the set ON.
2. Press the
?/1
button while holding the VIDEO/SAT button
depressed to toggle between “SAT” and “VIDEO.” The
selected mode is displayed.
[Aging Mode]
This mode can be used for operation check Tape deck section.
• If an error occurred:
The aging operation stops and is displayed status.
• If no error occurs:
The aging operation continues repeatedly
Aging mode in Tape Deck section
Procedure:
1. Load the tapes into the decks A and B respectively.
2. Press
?/1
button on the set ON
3. Select the function “TAPE A”
4. Press x button continuously, then press X and [TAPE A/B]
buttons. and aging mode is started.
5. To exit from the aging mode perform [Cold Reset].
• In the aging mode ,the program is executed in the following
sequence.
Step Operation Display
1 Rewind the TAPE A TAPE A AG-1
2 Rewind the TAPE B TAPE B AG-1
3 Play the TAPE A (t) (2 minute) TAPE A AG-2
4 F•F. (AMS) the TAPE A TAPE A AG-3
5 Play the TAPE A (T) (2 minute) TAPE A AG-4
6 Rewind the TAPE A TAPE A AG-5
7 Play the TAPE B (t) (2 minute) TAPE B AG-2
8 F•F.(AMS) the TAPE B TAPE B AG-3
9 Play the TAPE B (T) (2 minute) TAPE B AG-4
10 Rewind the TAPE B TAPE B AG-5
[GC Test Mode]
• All fluorecent segments and LEDs are tested.
• Microprocessor virsion.
• Keyboard and jog check.
• Display check.
Procedure:
1. To enter the test mode, press x button coutinuously, then
press X and [TUNER/BAND] buttons.
2. All segments and LEDs (without STANDBY LED) are turned
on.
3. Press the [TUNING -] button to increment the microprocessor
software version.
4. Press the [TUNING -] button to change the indication for the
microprocessor software version.
5. Press the b B button to set the check mode for the entries
(KEY, JOG, etc.).
6. Press the X button to display the current VACS level.
7. Press the x button to enter the mode to check the display. If
you press this button repeatedly, the display will change
sequentially as the button is pressed.
8. Press x button coutinuously, then press X and [TUNER/BAND]
buttons.
[MC Test Mode] (Amplifier SECTION)
• This mode is used to test the function of the amplifier section.
Procedure:
1. Press
?/1
button to turn the set ON.
2. To enter the test mode, press x button coutinuously, then
press X and z START buttons.
3. Turn [VOLUME] knob to counter-clockwise, the function of
the equalizer is set to “MIN”.
4. Turn [VOLUME] knob to clockwise, the function of the
equalizer is set to “MAX”.
5. Whenever turn [SOUND MODE] knob to clockwise, the display
switches as follows.
“TONE MAX” t“TONE MIN” t“TONE FLAT”
6. Press [DSGX] button to select DBFB ON or OFF.
7. To exit from this mode, press
?/1
button to turn the set
OFF.
8. Press
?/1
button to turn the set ON.
9. To enter the test mode, press x button coutinuously, then
press X and z START buttons.
[MC Test Mode] (Tape section)
• This mode is used to test the functions of the Tape section.
Procedure:
1. Press
?/1
button to turn the set ON.
2. To enter the test mode, press x button coutinuously, then
press X and z START buttons.
3. While holding the [DIMMER] button depressed, turn the ALC
ON.
4. Press the z START button to start REC (recording).
5. While recording, press the [TUNING +] button to perform
automatic rewind and automatic playback (for FF version).
Also, press the [TUNING -] button to perform automatic rewind
and automatic playback (for FR version).
6. Select the function “TAPE A” or “TAPE B”
To Next Page
