HCD-NXM2D
6060
HCD-NXM2D
•WAVEFORMS
– MAIN BOARD –
IC401 0 XC-IN
VOL/DIV : 0.5 V AC
TIME/DIV : 2.0 µ sec
2
IC401 qd X-OUT
VOL/DIV : 0.5 V AC
TIME/DIV : 50 nsec
1
1.5Vp-p
32.768KHz
1.5Vp-p
16MHz
– DMB07 BOARD –
IC701
170 XTL1
VOL/DIV : 2 V AC
TIME/DIV : 20 nsec
2
IC901 r; XTAL
VOL/DIV : 1 V AC
TIME/DIV : 20 nsec
7
IC207 119 VDAC_4
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
1
5.2Vp-p
33MHz
3.2Vp-p
20 MHz
0.7Vp-p
H
3
IC906 8 XTO
VOL/DIV : 1 V AC
TIME/DIV : 20 nsec
3.4Vp-p
27 MHz
4
IC509 el FE
VOL/DIV : 0.1 V AC
TIME/DIV : 2 msec
0.1Vp-p
5
IC509 ra TE
VOL/DIV : 0.1 V AC
TIME/DIV : 2 msec
0.1Vp-p
6
IC509 t; RFAC
VOL/DIV : 0.5 V AC
TIME/DIV : 0.1 µ sec
1.1 Vp-
p
8
IC207 122 VDAC_3
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
9
IC207 125 VDAC_2
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
1.1 Vp-p
1H
0
IC509 128 VDAC_1
VOL/DIV : 1 V AC
TIME/DIV : 20 µ sec
0.8 Vp-
p
qa
IC207 131 VDAC_0
VOL/DIV : 1 V AC
TIME/DIV : 20 µ sec
1.2 Vp-
p
qs
IC207 139 X IN
VOL/DIV : 1 V AC
TIME/DIV : 20 nsec
4Vp-p
15.3 MHz
0.7 Vp-
p
H
qd
IC207 148 LRCK
VOL/DIV : 1 V AC
TIME/DIV : 5 µ sec
3.3Vp-p
47 KHz
qf
IC207 149 BCK
VOL/DIV : 1 V AC
TIME/DIV : 0.2 µ sec
3.2 Vp-p
1.5MHz
– RF BOARD –
IC001 1 DVD RFP
VOL/DIV : 0.2 V AC
TIME/DIV : 100 nsec
2
IC001 el TE
VOL/DIV : 0.5 V AC
TIME/DIV : 1 msec
1
0.7Vp-
p
1.8Vp-p
3
IC001 r; FE
VOL/DIV : 0.1 V AC
TIME/DIV : 1 msec
0.3Vp-p
4
IC001 tj RFAC
VOL/DIV : 0.5 V AC
TIME/DIV : 100 nsec
1.2Vp-p
– VIDEO BOARD –
IC1101 0 CY IN
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
2
IC1101 qs CB IN
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
7
IC1101 wa Y OUT
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
1
2Vp-p
H
3
IC1101 qf CR IN
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
4
IC1101 qh CR OUT
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
5
IC1101 qk CB OUT
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
6
IC1101 w; CY OUT
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
8
IC1101 wd CVBS OUT
VOL/DIV : 1 V AC
TIME/DIV : 20 µ sec
9
IC1101 wh C OUT
VOL/DIV : 1 V AC
TIME/DIV : 20 µ sec
0
IC1101 2 C IN
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
qa
IC1101 6 Y IN
VOL/DIV : 0.5 V AC
TIME/DIV : 20 µ sec
1Vp-p
H
0.7Vp-p
H
0.7Vp-p
H
1.5Vp-p
H
1.5Vp-p
H
2Vp-p
H
2.6Vp-p
1.8Vp-p
1Vp-p
1Vp-
p
H
