Sony HCD-NXM2D - Front Amp Board Components

86
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description RemarksRef. No. Part No. Description Remarks
FL703 1-234-177-21 FILTER, CHIP EMI
FL705 1-234-177-21 FILTER, CHIP EMI
FL706 1-234-177-21 FILTER, CHIP EMI
FL901 1-234-177-21 FILTER, CHIP EMI
FL903 1-234-177-21 FILTER, CHIP EMI
FL908 1-234-177-21 FILTER, CHIP EMI
< IC >
IC111 6-550-554-01 TRANSISTOR UM6K1NL02TN
IC203 6-704-069-01 IC MT48LC4M32B2P-6-Y15W
* IC204 6-703-671-01 IC BR9040F-WE2
IC206 6-804-579-01 IC MBM29PL32BM90TN-NXM0401
IC207 6-704-630-01 IC ZIVA5X-C2F
IC211 6-700-398-01 IC uPC2918T-E1
IC231 8-759-549-21 IC SN74LV573APWR
IC232 8-759-549-21 IC SN74LV573APWR
IC233 8-759-549-21 IC SN74LV573APWR
IC252 8-759-680-48 IC TC7WH157FK (TE85R)
IC331 6-703-788-01 IC PCM1751DBQR
IC392 8-759-583-47 IC uPC2933T-E2
IC501 6-702-157-01 IC FAN8035L
IC502 8-759-583-47 IC uPC2933T-E2
IC503 8-759-058-43 IC NJM3404AV
IC509 8-752-408-73 IC CXD3068Q
IC701 6-703-552-01 IC TMC57929PGF-RDP
IC703 8-759-058-43 IC NJM3404AV
IC706 8-759-564-30 IC MSM51V18165B-60TSKR1
IC901 8-753-228-87 IC CXP973064-245R
IC902 8-759-649-48 IC SN74AHC1G32DCKR
IC903 6-704-004-01 IC BR24L16F-WE2
IC904 6-704-753-01 IC SN74AHC2G74HDCUR
IC906 6-700-407-01 IC SM8707GV-G-E2
IC907 8-759-583-47 IC uPC2933T-E2
< JUMPER RESISTOR >
JW392 1-216-864-11 SHORT CHIP 0
JW801 1-218-990-11 SHORT CHIP 0
JW802 1-218-990-11 SHORT CHIP 0
JW803 1-218-990-11 SHORT CHIP 0
JW804 1-218-990-11 SHORT CHIP 0
JW805 1-218-990-11 SHORT CHIP 0
JW806 1-218-990-11 SHORT CHIP 0
< COIL >
L103 1-216-296-11 SHORT CHIP 0
L501 1-216-296-11 SHORT CHIP 0
L704 1-412-031-11 INDUCTOR 47uH
L901 1-412-031-11 INDUCTOR 47uH
< TRANSISTOR >
Q202 8-729-929-26 TRANSISTOR DTC114TE
Q901 8-729-929-26 TRANSISTOR DTC114TE
< RESISTOR >
R10 1-216-801-11 METAL CHIP 22 5% 1/10W
R11 1-216-801-11 METAL CHIP 22 5% 1/10W
R12 1-216-801-11 METAL CHIP 22 5% 1/10W
R13 1-216-801-11 METAL CHIP 22 5% 1/10W
R14 1-216-801-11 METAL CHIP 22 5% 1/10W
R15 1-216-801-11 METAL CHIP 22 5% 1/10W
R213 1-218-939-11 RES-CHIP 68 5% 1/16W
R215 1-216-864-11 SHORT CHIP 0
R217 1-216-864-11 SHORT CHIP 0
R218 1-216-864-11 SHORT CHIP 0
R220 1-216-864-11 SHORT CHIP 0
R227 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R230 1-216-803-11 METAL CHIP 33 5% 1/10W
R231 1-216-803-11 METAL CHIP 33 5% 1/10W
R232 1-216-803-11 METAL CHIP 33 5% 1/10W
R234 1-216-833-11 METAL CHIP 10K 5% 1/10W
R239 1-216-809-11 METAL CHIP 100 5% 1/10W
R240 1-216-841-11 METAL CHIP 47K 5% 1/10W
R241 1-216-864-11 SHORT CHIP 0
R244 1-216-821-11 METAL CHIP 1K 5% 1/10W
R245 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R246 1-216-833-11 METAL CHIP 10K 5% 1/10W
R247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R248 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R250 1-216-864-11 SHORT CHIP 0
R251 1-216-864-11 SHORT CHIP 0
R253 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R254 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R255 1-216-864-11 SHORT CHIP 0
R257 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R259 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R260 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R261 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R263 1-218-285-11 METAL CHIP 75 5% 1/10W
R264 1-218-285-11 METAL CHIP 75 5% 1/10W
R265 1-218-285-11 METAL CHIP 75 5% 1/10W
R266 1-218-285-11 METAL CHIP 75 5% 1/10W
R267 1-218-285-11 METAL CHIP 75 5% 1/10W
R268 1-216-864-11 SHORT CHIP 0
R269 1-216-864-11 SHORT CHIP 0
R270 1-216-864-11 SHORT CHIP 0
R271 1-216-809-11 METAL CHIP 100 5% 1/10W
R272 1-216-809-11 METAL CHIP 100 5% 1/10W
R273 1-216-864-11 SHORT CHIP 0
R274 1-216-864-11 SHORT CHIP 0
R275 1-216-864-11 SHORT CHIP 0
R276 1-216-864-11 SHORT CHIP 0
R277 1-216-864-11 SHORT CHIP 0
R278 1-218-285-11 METAL CHIP 75 5% 1/10W
R279 1-218-285-11 METAL CHIP 75 5% 1/10W
R280 1-218-285-11 METAL CHIP 75 5% 1/10W
R281 1-218-285-11 METAL CHIP 75 5% 1/10W
R282 1-218-285-11 METAL CHIP 75 5% 1/10W
R283 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R284 1-218-829-11 METAL CHIP 180 0.5% 1/10W
R288 1-216-864-11 SHORT CHIP 0
R290 1-216-809-11 METAL CHIP 100 5% 1/10W
R291 1-216-809-11 METAL CHIP 100 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
R299 1-216-820-11 METAL CHIP 820 5% 1/10W
R301 1-216-821-11 METAL CHIP 1K 5% 1/10W
