93
HCD-NXM2D
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C908 1-126-767-11 ELECT 1000uF 20% 16V
C910 1-126-767-11 ELECT 1000uF 20% 16V
C911 1-165-718-21 ELECT 3300uF 20% 6.3V
C912 1-126-916-11 ELECT 1000uF 20% 6.3V
C914 1-126-767-11 ELECT 1000uF 20% 16V
C915 1-165-718-21 ELECT 3300uF 20% 6.3V
C916 1-126-916-11 ELECT 1000uF 20% 6.3V
C919 1-126-964-11 ELECT 10uF 20% 50V
C920 1-126-964-11 ELECT 10uF 20% 50V
C930 1-126-768-11 ELECT 2200uF 20% 16V
C952 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C953 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-691-769-11 PLUG (MICRO CONNECTOR) 7P
* CN102 1-774-876-21 CONNECTOR, BOARD TO BOARD 8P
CN103 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P
CN108 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE) 4P
CN109 1-784-774-11 CONNECTOR, FFC 13P
CN110 1-784-776-11 CONNECTOR, FFC 15P
CN112 1-784-766-11 CONNECTOR, FFC 5P
CN200 1-793-565-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN202 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN204 1-568-830-11 CONNECTOR, FFC 11P
* CN301 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
* CN302 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN303 1-784-774-11 CONNECTOR, FFC 13P
CN372 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D181 8-719-988-61 DIODE 1SS355TE-17
D182 8-719-988-61 DIODE 1SS355TE-17
D183 8-719-988-61 DIODE 1SS355TE-17
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-988-61 DIODE 1SS355TE-17
D321 8-719-988-61 DIODE 1SS355TE-17
D322 8-719-988-61 DIODE 1SS355TE-17
D391 8-719-988-61 DIODE 1SS355TE-17
D392 8-719-988-61 DIODE 1SS355TE-17
D393 8-719-988-61 DIODE 1SS355TE-17
D394 8-719-988-61 DIODE 1SS355TE-17
D395 8-719-988-61 DIODE 1SS355TE-17
D396 8-719-988-61 DIODE 1SS355TE-17
D397 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-080-53 DIODE RK36LF-B3
D902 8-719-080-53 DIODE RK36LF-B3
D903 6-500-522-31 DIODE 10EDB40-TB5
D904 8-719-988-61 DIODE 1SS355TE-17
D905 8-719-083-58 DIODE UDZSTE-173.9B
< EARTH TERMINAL >
EP901 1-537-738-21 TERMINAL, GROUND
< FERRITE BEAD >
FB30 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB34 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB50 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB54 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB80 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB84 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB201 1-216-864-11 SHORT CHIP 0
FB903 1-410-397-21 FERRITE 1.1uH
< IC >
IC101 6-705-667-01 IC M61537FP-RF0G
IC301 8-749-019-25 IC TOTX141 (OPTICAL OUT)
IC391 8-759-532-64 IC M62703SL-TP
IC401 6-803-927-01 IC M3062CMEN-A01FPU0
IC901 8-759-701-59 IC NJM78M09FA
IC902 8-759-701-59 IC NJM78M09FA
IC903 8-759-231-53 IC TA7805S
IC904 6-700-897-01 IC PQ12RD21
IC905 6-700-812-01 IC SI-8050JF
IC906 6-700-813-01 IC SI-8033JF
IC951 6-703-679-11 IC PT8300R-TP
< JACK >
J101 1-793-526-21 JACK, PIN 4P (VIDEO (MD))
< SHORT >
JR7 1-216-864-11 SHORT CHIP 0
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-296-11 SHORT CHIP 0
JR104 1-216-296-11 SHORT CHIP 0
JR105 1-216-296-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0
JR107 1-216-296-11 SHORT CHIP 0
JR108 1-216-296-11 SHORT CHIP 0
JR109 1-216-296-11 SHORT CHIP 0
JR110 1-216-864-11 SHORT CHIP 0
JR111 1-216-296-11 SHORT CHIP 0
JR112 1-216-864-11 SHORT CHIP 0
JR113 1-216-296-11 SHORT CHIP 0
JR114 1-216-864-11 SHORT CHIP 0
JR115 1-216-296-11 SHORT CHIP 0
JR116 1-216-864-11 SHORT CHIP 0
JR117 1-216-296-11 SHORT CHIP 0
JR118 1-216-864-11 SHORT CHIP 0
JR119 1-216-864-11 SHORT CHIP 0
JR120 1-216-864-11 SHORT CHIP 0
JR121 1-216-864-11 SHORT CHIP 0
JR122 1-216-296-11 SHORT CHIP 0
JR123 1-216-864-11 SHORT CHIP 0
JR124 1-216-296-11 SHORT CHIP 0
JR125 1-216-864-11 SHORT CHIP 0
JR126 1-216-296-11 SHORT CHIP 0
JR127 1-216-296-11 SHORT CHIP 0
JR128 1-216-864-11 SHORT CHIP 0
JR129 1-216-864-11 SHORT CHIP 0
JR130 1-216-864-11 SHORT CHIP 0
JR131 1-216-296-11 SHORT CHIP 0
JR132 1-216-296-11 SHORT CHIP 0
JR133 1-216-864-11 SHORT CHIP 0
JR203 1-216-864-11 SHORT CHIP 0
MAIN
