100
HCD-SA30
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C191 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C192 1-216-864-11 METAL CHIP 0 5% 1/16W
C193 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C194 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(AEP, UK, RU)
C195 1-164-739-11 CERAMIC CHIP 560PF 5.00% 50V
(AEP, UK, RU)
C196 1-126-963-11 ELECT 4.7uF 20.00% 50V
(AEP, UK, RU)
C197 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C198 1-216-864-11 METAL CHIP 0 5% 1/16W
C199 1-126-947-11 ELECT 47uF 20.00% 16V
(AEP, UK, RU)
C200 1-216-864-11 METAL CHIP 0 5% 1/16W
C201 1-216-864-11 METAL CHIP 0 5% 1/16W
C203 1-128-551-11 ELECT 22uF 20.00% 25V
C204 1-126-795-11 ELECT 10uF 20.00% 50V
C205 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C206 1-164-730-11 CERAMIC CHIP 0.0012uF 10.00% 50V
C207 1-216-864-11 METAL CHIP 0 5% 1/16W
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-128-551-11 ELECT 22uF 20.00% 25V
C210 1-128-551-11 ELECT 22uF 20.00% 25V
C211 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C212 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C214 1-115-156-11 CERAMIC CHIP 1uF 10V
C215 1-128-551-11 ELECT 22uF 20.00% 25V
C216 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C217 1-128-551-11 ELECT 22uF 20.00% 25V
C218 1-216-864-11 METAL CHIP 0 5% 1/16W
C219 1-216-864-11 METAL CHIP 0 5% 1/16W
C220 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C226 0-000-000-00
C227 1-216-864-11 METAL CHIP 0 5% 1/16W
C228 1-216-864-11 METAL CHIP 0 5% 1/16W
C229 1-216-864-11 METAL CHIP 0 5% 1/16W
C230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-216-864-11 METAL CHIP 0 5% 1/16W
C243 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP, UK, RU)
C245 1-164-380-11 CERAMIC CHIP 51PF 5% 50V
(AEP, UK, RU)
C246 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
(AEP, UK, RU)
C247 1-126-964-11 ELECT 10uF 20.00% 50V
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C249 1-126-933-11 ELECT 100uF 20.00% 16V
C250 1-126-964-11 ELECT 10uF 20.00% 50V
C260 1-126-964-11 ELECT 10uF 20.00% 50V
C278 1-128-551-11 ELECT 22uF 20.00% 25V
< CONNECTOR >
CN101 1-784-869-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
(EXCEPT AEP, UK, RU)
CN101 1-784-871-21 CONNECTOR, FFC
(LIF (NON-ZIF)) 19P
(AEP, UK
, RU
)
* CN104 1-568-942-11 PIN, CONNECTOR 4P (EXCEPT AEP, UK, RU)
* CN104 1-568-948-11 PIN, CONNECTOR 10P (AEP, UK, RU)
CN105 1-784-733-11 CONNECTOR, FFC 11P
CN106 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN107 1-784-865-01 CONNECTOR, FFC (LIF (NON-ZIF)) 13
< DIODE >
D103 8-719-988-61 DIODE 1SS355TE-17 (AEP, UK, RU)
D201 8-719-056-78 DIODE UDZ-TE-17-4.3B (AEP, UK, RU)
< FERRITE BEAD >
FB101 1-216-864-11 METAL CHIP 0 5% 1/16W
FB102 1-216-864-11 METAL CHIP 0 5% 1/16W
FB103 1-412-002-31 INDUCTOR 4.7uH
FB104 1-500-284-21 FERRITE 0uH
FB106 1-410-985-42 INDUCTOR 0.22uH
FB109 1-216-864-11 METAL CHIP 0 5% 1/16W
FB112 1-216-864-11 METAL CHIP 0 5% 1/16W
FB202 1-216-864-11 METAL CHIP 0 5% 1/16W
FB203 1-412-002-31 INDUCTOR 4.7uH
< IC >
IC103 6-702-335-01 IC MM1568
IC104 6-702-334-01 IC MM1510
IC105 8-759-701-40 IC NJM2100M (TE2)
IC106 8-759-284-49 IC NJM2285V-TE2
IC107 8-759-385-76 IC MC14052 BDR2
IC108 8-759-557-36 IC BU1924F-E2 (AEP, UK, RU)
IC109 8-759-696-10 IC NJM2235V (TE2)
IC110 8-759-701-40 IC NJM2100M (TE2)
< JACK >
J104 1-817-448-11 JACK, PIN 9P (VIDEO1/VIDEO2)
J105 1-694-920-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)(EXCEPT AEP, UK, RU)
< COIL >
L111 1-469-525-91 INDUCTOR 10uH
L112 1-469-525-91 INDUCTOR 10uH
L123 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q101 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q102 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q103 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q135 8-729-027-23 TRANSISTOR DTA114EKA-T146
(EXCEPT AEP, UK, RU)
Q136 1-801-806-11 TRANSISTOR DTC144EKA-T146
(EXCEPT AEP, UK, RU)
Q137 8-729-900-53 TRANSISTOR DTC114EKA-T146
(AEP, UK, RU)
Q138 8-729-027-23 TRANSISTOR DTA114EKA-T146
(AEP, UK, RU)
Q139 8-729-900-53 TRANSISTOR DTC114EKA-T146
(AEP, UK, RU)
Q140 8-729-027-23 TRANSISTOR DTA114EKA-T146
(AEP, UK, RU)
Q141 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
(AEP, UK, RU)
Q142 8-729-900-53 TRANSISTOR DTC114EKA-T146
(AEP, UK, RU)
