For schematic diagrams.
Note:
• All capacitors are in μF unless otherwise noted. pF: μμF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
•
f
: internal component.
• C : panel designation.
For printed wiring boards.
Note:
• X : parts extracted from the component side.
•
a
: Through hole.
• b : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
• A : B+ Line.
• B : B– Line.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
• Voltages and waveforms are dc with respect to ground in
service mode.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
no mark : STOP
• Circled numbers refer to waveforms.
• Signal path.
F : AUDIO
J : CD PLAY
c : DVD PLAY
d : TUNER
L : VIDEO
E : Y
r : COMPONENT VIDEO
q : R, G, B
e : AUX IN
I : SACD PLAY
• Abbreviation
AUS : Australian model
EA : Saudi Arabia model
HK : Hong Kong model
KR : Korean model
RU : Russian model
SP : Singapole model
TW : Taiwan model
Caution:
Pattern face side: Parts on the pattern face side seen from
(SIDE A) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(SIDE B) the parts face are indicated.
SECTION 5
DIAGRAMS
5-1. Circuit Board Location
AEP, UK, Russian models
MS-128 board
RF board
FRONT board
HP board
AMP board
DMB03 board
POWER board
MS-128 board
UCOM board
STANDBY board
SCART board
TUNER
I/O board
RF board
AMP board
DMB03 board
POWER board
COMPONENT board
TUNER
except AEP, UK, Russian models
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
Note: The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
