102
HCD-SA30
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R223 1-216-815-11 METAL CHIP 330 5% 1/16W
R224 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R225 1-216-839-11 METAL CHIP 33K 5% 1/16W
R226 1-216-839-11 METAL CHIP 33K 5% 1/16W
R227 1-216-839-11 METAL CHIP 33K 5% 1/16W
R229 1-216-821-11 METAL CHIP 1K 5% 1/16W
R230 1-216-813-11 METAL CHIP 220 5% 1/16W
R231 1-216-821-11 METAL CHIP 1K 5% 1/16W
R233 1-216-813-11 METAL CHIP 220 5% 1/16W
R234 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R235 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
R236 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP, UK, RU)
R237 1-216-813-11 METAL CHIP 220 5% 1/16W
R238 1-216-813-11 METAL CHIP 220 5% 1/16W
R239 1-216-833-11 METAL CHIP 10K 5% 1/16W
R240 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP, UK, RU)
R241 1-216-833-11 METAL CHIP 10K 5% 1/16W
R243 1-216-833-11 METAL CHIP 10K 5% 1/16W
R244 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(AEP, UK, RU)
R245 1-216-814-11 METAL CHIP 270 5% 1/16W
(AEP, UK, RU)
R248 1-216-833-11 METAL CHIP 10K 5% 1/16W
R252 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R254 1-216-813-11 METAL CHIP 220 5% 1/16W
R260 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP, UK, RU)
R263 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP, UK, RU)
R267 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT AEP, UK, RU)
R269 1-216-296-11 SHORT CHIP 0
R273 1-216-296-11 SHORT CHIP 0
R274 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R276 1-216-833-11 METAL CHIP 10K 5% 1/16W
R277 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R278 1-216-864-11 METAL CHIP 0 5% 1/16W
R279 1-216-864-11 METAL CHIP 0 5% 1/16W
R285 1-216-864-11 METAL CHIP 0 5% 1/16W
R288 1-216-833-11 METAL CHIP 10K 5% 1/16W
R290 1-216-864-11 METAL CHIP 0 5% 1/16W
R291 1-216-864-11 METAL CHIP 0 5% 1/16W
R292 1-216-845-11 METAL CHIP 100K 5% 1/16W
< VIBRATOR >
X201 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz (AEP, UK, RU)
************************************************************
MS-128 BOARD
*************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-357-12 SWITCH, LEVER (SLIDE)
************************************************************
A-4731-576-A POWER BOARD, COMPLETE
(E, SP, HK, TW, EA)
***********************
A-4733-173-A POWER BOARD, COMPLETE (AEP, UK, RU, AUS)
***********************
A-4747-411-A POWER BOARD, COMPLETE
(KR)
***********************
< CAPACITOR >
0 C905 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
C906 1-137-401-11 MYLAR 0.22uF 5.00% 100V
C907 1-119-940-51 ELECT 4700uF 20.00% 50V
C908 1-126-965-91 ELECT 22uF 20.00% 50V
C909 1-126-964-11 ELECT 10uF 20.00% 50V
C910 1-104-613-21 ELECT 4700uF 20.00% 35V
C911 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C912 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C913 1-131-704-11 FILM 1uF 5% 50V
C914 1-126-767-11 ELECT 1000uF 20.00% 16V
C915 1-131-704-11 FILM 1uF 5% 50V
C916 1-126-927-11 ELECT 2200uF 20.00% 10V
C917 1-131-704-11 FILM 1uF 5% 50V
C918 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C919 1-126-768-11 ELECT 2200uF 20.00% 16V
C920 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C921 1-104-665-11 ELECT 100uF 20.00% 10V
C922 1-126-960-11 ELECT 1uF 20.00% 50V
C923 1-107-826-11 CERAMIC CHIP 0.1uF 10% 10V
C924 1-131-704-11 FILM 1uF 5% 50V
C930 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C931 1-126-947-11 ELECT 47uF 20.00% 35V
< CONNECTOR >
CN901 1-774-108-11 PIN, CONNECTOR (PC BOARD)
CN902 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
(AEP, UK, RU, AUS)
CN902 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(EXCEPT AEP, UK, RU, AUS)
CN903 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN904 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
CN905 1-568-951-11 PIN, CONNECTOR 2P
< DIODE >
D901 6-500-522-11 DIODE 10EDB40-TA2B5
D902 6-500-250-01 DIODE D15XB20-4001
D903 6-500-522-11 DIODE 10EDB40-TA2B5
D904 8-719-923-93 DIODE MTZJ-T-77-16C
D905 8-719-921-44 DIODE MTZJ-T-77-5.1C
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D908 8-719-210-21 DIODE 11EQS04-TA1B
D909 8-719-079-47 DIODE RK36LF-A4
D910 8-719-079-47 DIODE RK36LF-A4
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 6-500-522-11 DIODE 10EDB40-TA2B5
D915 6-500-522-11 DIODE 10EDB40-TA2B5
I/O MS-128 POWER
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
