HCD-SA30
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D918 6-500-522-11 DIODE 10EDB40-TA2B5
D920 8-719-110-03 DIODE MTZJ-T-77-7.5C
< GROUND TERMINAL >
EP901 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC901 6-701-760-01 IC uPC3504AHF
IC903 6-701-021-01 IC SI-8120JF
IC904 8-759-474-09 IC SI-8050S-LF1101
IC905 6-700-813-01 IC SI-8033JF
< COIL >
L901 1-456-419-11 INDUCTOR 0uH
L902 1-456-419-11 INDUCTOR 0uH
L903 1-456-419-11 INDUCTOR 0uH
< TRANSISTOR >
Q901 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q902 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q903 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q904 6-550-514-01 TRANSISTOR 2SK1189
Q906 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q908 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
< RESISTOR >
R902 1-216-845-11 METAL CHIP 100K 5% 1/16W
R903 1-216-819-11 METAL CHIP 680 5% 1/16W
R904 1-216-845-11 METAL CHIP 100K 5% 1/16W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R906 1-216-837-11 METAL CHIP 22K 5% 1/16W
R907 1-216-837-11 METAL CHIP 22K 5% 1/16W
R908 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R909 1-216-837-11 METAL CHIP 22K 5% 1/16W
R910 1-216-837-11 METAL CHIP 22K 5% 1/16W
R911 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R912 1-216-821-11 METAL CHIP 1K 5% 1/16W
R913 1-216-833-11 METAL CHIP 10K 5% 1/16W
R914 1-216-815-11 METAL CHIP 330 5% 1/16W
R915 1-216-810-11 METAL CHIP 120 5% 1/16W
R916 1-216-835-11 METAL CHIP 15K 5% 1/16W
R917 1-216-839-11 METAL CHIP 33K 5% 1/16W
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R920 1-247-791-91 CARBON 22 5% 1/4W F
R921 1-216-845-11 METAL CHIP 100K 5% 1/16W
R922 1-216-837-11 METAL CHIP 22K 5% 1/16W
< RELAY >
0 RY901 1-755-467-11 RELAY (POWER)
< SWITCH >
0 S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E, SP, HK, TW, EA, KR)
< TRANSFORMER >
0 T901 1-437-844-11 TRANSFORMER, POWER (E, SP, HK, TW, EA, KR)
0 T901 1-437-730-11 TRANSFORMER, POWER (AEP, UK, RU, AUS)
************************************************************
A-4728-690-A RF BOARD, COMPLETE
******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
C006 1-128-993-21 ELECT CHIP 22uF 20% 10V
C008 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C009 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C010 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C011 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C012 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C013 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C014 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C015 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C016 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C017 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C018 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
C019 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C023 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C026 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C027 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C032 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C033 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C034 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C036 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C037 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C038 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C039 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C040 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C041 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C042 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C049 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
< CONNECTOR >
CN001 1-815-031-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN002 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN003 1-784-861-21 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D002 8-719-988-61 DIODE 1SS355TE-17
POWER RF
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
