Sony HCD-SA30 - Page 104

104
HCD-SA30
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC001 6-703-551-01 IC CXD1881AR
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R001 1-218-668-11 METAL CHIP 100 0.5% 1/10W
R003 1-216-803-11 METAL CHIP 33 5% 1/16W
R004 1-216-803-11 METAL CHIP 33 5% 1/16W
R005 1-216-841-11 METAL CHIP 47K 5% 1/16W
R006 1-216-817-11 METAL CHIP 470 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-841-11 METAL CHIP 47K 5% 1/16W
R010 1-216-817-11 METAL CHIP 470 5% 1/16W
R011 1-216-864-11 METAL CHIP 0 5% 1/16W
R012 1-216-864-11 METAL CHIP 0 5% 1/16W
R013 1-216-864-11 METAL CHIP 0 5% 1/16W
R014 1-216-864-11 METAL CHIP 0 5% 1/16W
R015 1-216-864-11 METAL CHIP 0 5% 1/16W
R016 1-216-864-11 METAL CHIP 0 5% 1/16W
R017 1-216-864-11 METAL CHIP 0 5% 1/16W
R018 1-216-864-11 METAL CHIP 0 5% 1/16W
R019 1-216-864-11 METAL CHIP 0 5% 1/16W
R020 1-216-864-11 METAL CHIP 0 5% 1/16W
R021 1-216-864-11 METAL CHIP 0 5% 1/16W
R022 1-216-813-11 METAL CHIP 220 5% 1/16W
R023 1-216-820-11 METAL CHIP 820 5% 1/16W
R024 1-216-864-11 METAL CHIP 0 5% 1/16W
R025 1-216-809-11 METAL CHIP 100 5% 1/16W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/10W
R027 1-216-864-11 METAL CHIP 0 5% 1/16W
R028 1-216-864-11 METAL CHIP 0 5% 1/16W
R029 1-216-864-11 METAL CHIP 0 5% 1/16W
R032 1-216-809-11 METAL CHIP 100 5% 1/16W
R033 1-216-864-11 METAL CHIP 0 5% 1/16W
R034 1-219-570-11 METAL CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/16W
R041 1-216-821-11 METAL CHIP 1K 5% 1/16W
************************************************************
A-4731-596-A SCART BOARD (AEP, UK, RU)
************
< CAPACITOR >
C130 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< FERRITE BEAD >
FB107 1-500-284-21 FERRITE 0uH (AEP, UK, RU)
FB108 1-500-284-21 FERRITE 0uH (AEP, UK, RU)
FB207 1-500-284-21 FERRITE 0uH (AEP, UK, RU)
FB208 1-500-284-21 FERRITE 0uH (AEP, UK, RU)
< JACK >
J101 1-815-911-11 CONNECTOR, SQUARE TYPE 21P (EURO AV)
(AEP, UK, RU)
< COIL >
L101 1-412-002-31 INDUCTOR 4.7uH (AEP, UK, RU)
L201 1-412-002-31 INDUCTOR 4.7uH (AEP, UK, RU)
< RESISTOR >
R159 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
R160 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
R161 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
R164 1-500-284-21 FERRITE 0uH (AEP, UK, RU)
R165 1-500-284-21 FERRITE 0uH (AEP, UK, RU)
R167 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
R286 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
R287 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, UK, RU)
************************************************************
1-687-083-12 STANDBY BOARD
**************
< CAPACITOR >
C808 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C832 1-126-795-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
* CN805 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D804 8-719-988-61 DIODE 1SS355TE-17
D812 8-719-300-71 DIODE SEL2210R-TP6 (STANDBY)
< IC >
IC801 8-759-826-34 IC NJL74H400A (g)
< RESISTOR >
R804 1-216-819-11 METAL CHIP 680 5% 1/16W
R810 1-216-805-11 METAL CHIP 47 5% 1/16W
R835 1-216-805-11 METAL CHIP 47 5% 1/16W
< SWITCH >
S831 1-786-220-11 SWITCH, KEY BOARD (@/1)
************************************************************
RF SCART STANDBY
