Sony HCD-SA30 - Page 105

105
HCD-SA30
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-4731-578-A UCOM BOARD, COMPLETE (E)
**********************
A-4731-588-A UCOM BOARD, COMPLETE (AEP, UK)
**********************
A-4733-199-A UCOM BOARD, COMPLETE (EA)
**********************
A-4733-207-A UCOM BOARD, COMPLETE (SP, HK, TW)
**********************
A-4733-221-A UCOM BOARD, COMPLETE (AUS)
**********************
A-4747-330-A UCOM BOARD, COMPLETE (KR)
**********************
A-4747-390-A UCOM BOARD, COMPLETE (RU)
**********************
< CAPACITOR >
C503 1-126-963-11 ELECT 4.7uF 20.00% 50V
C504 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C508 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C510 1-126-933-11 ELECT 100uF 20.00% 16V
C511 1-126-933-11 ELECT 100uF 20.00% 16V
C512 1-126-933-11 ELECT 100uF 20.00% 16V
C514 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C515 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C516 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C517 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C518 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C519 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C520 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C523 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C524 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C526 1-126-933-11 ELECT 100uF 20.00% 16V
C527 1-126-933-11 ELECT 100uF 20.00% 16V
C529 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C531 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C532 1-104-905-11 CAPACITOR 0.22F 5.5V
C533 1-126-947-11 ELECT 47uF 20.00% 16V
C534 1-126-963-11 ELECT 4.7uF 20.00% 50V
C535 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C536 1-126-933-11 ELECT 100uF 20.00% 16V
C537 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C539 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C540 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C541 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C542 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C545 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C546 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C547 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C548 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C550 1-126-934-11 ELECT 220uF 20.00% 16V
C551 1-126-935-11 ELECT 470uF 20.00% 10V
C552 1-126-934-11 ELECT 220uF 20.00% 10V
C553 1-126-947-11 ELECT 47uF 20.00% 10V
C554 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C555 1-126-934-11 ELECT 220uF 20.00% 10V
C583 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN501 1-784-778-11 CONNECTOR, FFC 17P
* CN503 1-564-704-11 PIN, CONNECTOR (SMALL TYPE)2P
CN507 1-784-213-11 CONNECTOR, FFC(LIF(NON-ZIF))15P
CN509 1-785-466-11 CONNECTOR, FFC/FPC 7P
CN510 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN511 1-564-512-11 PLUG, CONNECTOR 9P
* CN512 1-564-715-11 PIN, CONNECTOR (SMALL TYPE)13P
* CN513 1-784-365-31 CONNECTOR, FFC/FPC 5P
* CN514 1-784-365-31 CONNECTOR, FFC/FPC 5P
CN515 1-784-370-31 CONNECTOR, FFC/FPC 11P
CN516 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
(EXCEPT AEP, UK, RU)
CN516 1-779-287-11 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
(AEP, UK, RU)
< DIODE >
D502 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D514 8-719-988-61 DIODE 1SS355TE-17
D515 8-719-988-61 DIODE 1SS355TE-17
D516 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB501 1-216-295-91 SHORT CHIP 0
FB537 1-414-813-11 FERRITE 0uH
< IC >
IC501 6-802-608-01 IC uPD703260YGF-S01-JBT-A
IC502 8-759-598-69 IC BA6956AN
IC504 8-759-450-47 IC BA05T
IC505 8-759-450-47 IC BA05T
IC506 6-701-760-01 IC uPC3504AHF
IC507 8-759-231-57 IC TA7810S
IC580 8-759-666-13 IC PST9229NL
< JUMPER RESISTOR >
JR501 1-216-864-11 METAL CHIP 0 5% 1/16W
JR502 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L501 1-414-398-11 INDUCTOR 10uH
L502 1-414-398-11 INDUCTOR 10uH
L503 1-414-398-11 INDUCTOR 10uH
L504 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q501 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q502 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q503 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q504 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q505 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q513 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q514 8-729-040-20 TRANSISTOR RT1P137L-TP
UCOM
