Sony HCD-SA30 - Page 85

85
HCD-SA30
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 4-243-615-01 LID, CD
102 1-775-267-11 WIRE (FLAT TYPE)(29 CORE)
104 4-951-620-01 SCREW (2.6X8), +BVTP
105 4-900-386-01 SCREW
106 A-4731-576-A POWER BOARD, COMPLETE (E, SP, HK, TW, EA)
106 A-4733-173-A POWER BOARD, COMPLETE
(AEP, UK, RU, AUS)
106 A-4747-411-A POWER BOARD, COMPLETE (KR)
107 A-4731-596-A SCART BOARD (AEP, UK, RU)
108 1-500-511-11 CORE, FERRITE (AEP, UK, RU)
110 1-769-943-11 WIRE (FLAT TYPE)(11 CORE)
111 1-775-120-11 WIRE (FLAT TYPE)(13 CORE)
112 A-4731-582-A I/O BOARD, COMPLETE (E)
112 A-4731-592-A I/O BOARD, COMPLETE (AEP, UK, RU)
112 A-4733-126-A I/O BOARD, COMPLETE (SP, HK, TW, EA, AUS)
112 A-4747-336-A I/O BOARD, COMPLETE (KR)
115 1-775-082-11 WIRE (FLAT TYPE)(9 CORE)
116 A-4731-534-A AMP BOARD, COMPLETE (EXCEPT KR)
116 A-4747-315-A AMP BOARD, COMPLETE (KR)
117 1-827-313-11 WIRE (FLAT TYPE)(15 CORE)
118 1-775-152-11 WIRE (FLAT TYPE)(17 CORE)
(EXCEPT AEP, UK, RU)
118 1-775-169-11 WIRE (FLAT TYPE)(19 CORE)(AEP, UK, RU)
119 1-775-134-11 WIRE (FLAT TYPE)(15 CORE)
120 A-4731-578-A UCOM BOARD, COMPLETE (E)
120 A-4731-588-A UCOM BOARD, COMPLETE (AEP, UK)
120 A-4733-199-A UCOM BOARD, COMPLETE (EA)
120 A-4733-207-A UCOM BOARD, COMPLETE (SP, HK, TW)
120 A-4733-221-A UCOM BOARD, COMPLETE (AUS)
120 A-4747-330-A UCOM BOARD, COMPLETE (KR)
120 A-4747-390-A UCOM BOARD, COMPLETE (RU)
121 1-775-099-11 WIRE (FLAT TYPE)(11 CORE)
122 1-773-989-11 WIRE (FLAT TYPE)(5 CORE)
124 A-4731-638-A DMB03 BOARD, COMPLETE (E)
124 A-4733-104-A DMB03 BOARD, COMPLETE (TW)
124 A-4733-193-A DMB03 BOARD, COMPLETE (EA)
124 A-4733-201-A DMB03 BOARD, COMPLETE (SP)
124 A-4733-210-A DMB03 BOARD, COMPLETE (HK)
124 A-4733-215-A DMB03 BOARD, COMPLETE (AUS)
124 A-4733-223-A DMB03 BOARD, COMPLETE (AEP)
124 A-4733-257-A DMB03 BOARD, COMPLETE (UK)
124 A-4747-289-A DMB03 BOARD, COMPLETE (KR)
124 A-4747-384-A DMB03 BOARD, COMPLETE (RU)
125 4-244-969-01 FOOT
126 4-246-039-01 SEAL (VOL-SEL)(E, SP, HK, TW, EA, AUS)
127 3-970-608-11 SUMITITE (B3), +BV
0 T101 1-439-568-11 TRANSFORMER, POWER (TW)
0 T101 1-439-569-11 TRANSFORMER, POWER (EA)
0 T101 1-439-570-11 TRANSFORMER, POWER (AEP, UK, RU, AUS)
0 T101 1-439-571-11 TRANSFORMER, POWER (E, SP, HK, KR)
TU101 A-4730-143-A TUNER UNIT (E, SP, HK, TW, EA, MX, AUS)
TU101 A-4738-774-1 TUNER UNIT (AEP, UK,RU,KR)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
