98
HCD-SA30
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C811 1-126-795-11 ELECT 10uF 20.00% 50V
C813 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C814 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C816 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C819 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C820 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C821 1-126-795-11 ELECT 10uF 20.00% 50V
C822 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C823 1-126-795-11 ELECT 10uF 20.00% 50V
C824 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C825 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C827 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C828 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C829 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C830 1-126-795-11 ELECT 10uF 20.00% 50V
C833 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C834 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C835 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C836 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C837 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C838 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN801 1-784-739-11 CONNECTOR, FFC 17P
< DIODE >
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
D808 8-719-988-61 DIODE 1SS355TE-17
D809 8-719-988-61 DIODE 1SS355TE-17
D810 8-719-421-24 DIODE MA8039-H-TX
< FERRITE BEAD >
FB800 1-216-295-91 SHORT CHIP 0
FB801 1-414-813-11 FERRITE 0uH
FB802 1-216-295-91 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
FL801 1-518-867-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC802 8-759-643-83 IC PT6315
< JUMPER RESISTOR >
JR801 1-216-864-11 METAL CHIP 0 5% 1/16W
JR802 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L811 1-410-997-31 INDUCTOR 2.2uH (EXCEPT KR)
L811 1-410-997-41 INDUCTOR 2.2uH (KR)
< TRANSISTOR >
Q803 8-729-808-42 TRANSISTOR 2SD1624-T-TD
Q804 8-729-808-42 TRANSISTOR 2SD1624-T-TD
< RESISTOR >
R812 1-216-821-11 METAL CHIP 1K 5% 1/16W
R813 1-216-821-11 METAL CHIP 1K 5% 1/16W
R814 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R822 1-216-821-11 METAL CHIP 1K 5% 1/16W
R823 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R840 1-216-844-11 METAL CHIP 82K 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R846 1-216-845-11 METAL CHIP 100K 5% 1/16W
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R855 1-216-809-11 METAL CHIP 100 5% 1/16W
R874 1-216-839-11 METAL CHIP 33K 5% 1/16W
< SWITCH >
S800 1-477-173-11 ENCODER, ROTARY (VOLUME)
S811 1-786-220-11 SWITCH, KEY BOARD (FUNCTION)
S812 1-786-220-11 SWITCH, KEY BOARD (B)
S813 1-786-220-11 SWITCH, KEY BOARD (X)
S814 1-786-220-11 SWITCH, KEY BOARD (x)
S821 1-786-220-11 SWITCH, KEY BOARD (Z)
S822 1-786-220-11 SWITCH, KEY BOARD (>)
S823 1-786-220-11 SWITCH, KEY BOARD (.)
< TRANSFORMER >
T801 1-439-567-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR (POSITIVE) >
THP801 1-801-726-11 THERMISTOR, POSITIVE
THP802 1-801-726-11 THERMISTOR, POSITIVE
************************************************************
A-4731-552-A HP BOARD, COMPLETE (EXCEPT KR)
*******************
A-4747-323-A HP BOARD, COMPLETE (KR)
*******************
< CAPACITOR >
C802 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C803 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C876 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C881 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C883 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D883 8-719-988-61 DIODE 1SS355TE-17
D884 8-719-988-61 DIODE 1SS355TE-17
D885 8-719-058-24 DIODE RB501V-40TE-17
D887 8-719-058-24 DIODE RB501V-40TE-17
< GROUND TERMINAL >
EPT802 1-537-770-21 TERMINAL BOARD, GROUND
FRONT HP
