Sony HCD-SHAKE10 - DAMP Board Section Exploded View

54
HCD-SHAKE10/SHAKE30/HCDSHAKEX10/HCDSHAKEX30/HCDSHAKEX70
7-2. 2CH DAMP, 4CH DAMP BOARD SECTION
0 51 1-855-340-11 DC FAN
52 4-435-965-01 SCREW+PTPWH 2.6XL (DIA8.0)
53 A-2167-927-A 2CH DAMP BOARD, COMPLETE (SHAKE10/
SHAKE30/HCDSHAKEX10/HCDSHAKEX30)
53 A-2166-772-A 4CH DAMP BOARD, COMPLETE
(HCDSHAKEX70)
54 4-295-431-02 SPRING, LOADING
55 X-2590-779-2 PANEL, LOADING ASSY
#1 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
ns not supplied
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ns
ns
E
D
C
C
D
C
D
E
G
G
E
F
F
F
(SHAKE10/SHAKE30/
HCDSHAKEX10/HCDSHAKEX30)
(HCDSHAKEX70)
(HCDSHAKEX70)
(HCDSHAKEX70)
51
52
52
53
53
#1
#1
#1
#1
#1
#1
#1
55
54
ns
ns
ns
ns
back panel section
ns
ns
ns
ns
ns
