Sony HCD-SHAKE10 - Electrical Parts List; Semiconductor Components

61
HCD-SHAKE10/SHAKE30/HCDSHAKEX10/HCDSHAKEX30/HCDSHAKEX70
SECTION 8
ELECTRICAL PARTS LIST
A-2167-927-A 2CH DAMP BOARD, COMPLETE (SHAKE10/
SHAKE30/HCDSHAKEX10/HCDSHAKEX30)
*************************
< IC >
IC1005 6-722-001-01 IC 78D12AG-TN3-R
IC1006 6-722-002-01 IC 78D07AG-TN3-R
IC1007 6-722-003-01 IC 79D07AG-TN3-R
*************************************************************
A-2166-772-A 4CH DAMP BOARD, COMPLETE
(HCDSHAKEX70)
*************************
< IC >
IC1005 6-722-001-01 IC 78D12AG-TN3-R
IC1006 6-722-002-01 IC 78D07AG-TN3-R
IC1007 6-722-003-01 IC 79D07AG-TN3-R
*************************************************************
A-2183-157-A BAR CENTER BOARD, COMPLETE
(HCDSHAKEX70)
***************************
*************************************************************
A-2167-937-A FL BOARD, COMPLETE
******************
*************************************************************
A-2170-673-A HI-RGB LEFT BOARD, COMPLETE
***************************
*************************************************************
A-2183-269-A HI-RGB RIGHT BOARD, COMPLETE
(HCDSHAKEX70)
****************************
*************************************************************
A-2170-671-A HI-RGB RIGHT LED PC BO BOARD, COMPLETE
(SHAKE10/SHAKE30/HCDSHAKEX10/
HCDSHAKEX30)
*************************************
*************************************************************
IR BOARD
********
< IC >
IC010 6-600-894-01 IC SIR8441MH6FB5 (
)
*************************************************************
A-2167-940-A LED DRIVER BOARD, COMPLETE (SHAKE10/
SHAKE30/HCDSHAKEX10/HCDSHAKEX30)
A-2167-941-A LED DRIVER BOARD, COMPLETE
(HCDSHAKEX70)
**************************
*************************************************************
MIC BOARD
*********
< DIODE >
D2218 6-502-961-01 DI DA2J10100L
D2220 6-502-961-01 DI DA2J10100L
D2222 6-500-400-01 DIODE BAV99-215
D2223 6-500-400-01 DIODE BAV99-215
< FERRITE BEAD >
FB006 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB007 1-469-670-21 FERRITE, EMI (SMD) (2012)
< IC >
IC2101 6-713-989-01 IC NJM2783V (TE2)
IC2202 8-759-425-23 IC BA4558F-E2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
•
Due to standardization, replacements in
the parts list may be diff erent from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some diff erence from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
• Abbreviation
AR : Argentina model
AUS : Australian model
CND : Canadian model
E4 : African model
E12 : 220 – 240 V AC area in E model
EA : Saudi Arabia model
LA9 : Latin-American model
MY : Malaysia model
RU : Russian model
TH : Thai model
2CH DAMP
4CH DAMP
FLBAR CENTER
HI-RGB LEFT HI-RGB RIGHT
HI-RGB RIGHT LED PC BO
LED DRIVER MIC
IR
