Sony HCD-SHAKE10 - Switches and Miscellaneous Parts

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE10/SHAKE30/HCDSHAKEX10/HCDSHAKEX30/HCDSHAKEX70
64
JR1661 1-216-296-11 SHORT CHIP 0
JR1662 1-216-296-11 SHORT CHIP 0
JR1663 1-216-296-11 SHORT CHIP 0
JR1664 1-216-296-11 SHORT CHIP 0
JR1665 1-216-296-11 SHORT CHIP 0
JR1666 1-216-296-11 SHORT CHIP 0
JR1667 1-216-296-11 SHORT CHIP 0
JR1668 1-216-296-11 SHORT CHIP 0
JR1669 1-216-296-11 SHORT CHIP 0
JR1670 1-216-296-11 SHORT CHIP 0
JR1671 1-216-296-11 SHORT CHIP 0
JR1672 1-216-296-11 SHORT CHIP 0
JR1673 1-216-296-11 SHORT CHIP 0
JR1674 1-216-296-11 SHORT CHIP 0
JR1675 1-216-296-11 SHORT CHIP 0
JR1676 1-216-296-11 SHORT CHIP 0
JR1677 1-216-296-11 SHORT CHIP 0
JR1678 1-216-296-11 SHORT CHIP 0
JR1679 1-216-296-11 SHORT CHIP 0
JR1680 1-216-296-11 SHORT CHIP 0
JR1681 1-216-296-11 SHORT CHIP 0
JR1683 1-216-296-11 SHORT CHIP 0
JR1684 1-216-296-11 SHORT CHIP 0
JR1685 1-216-296-11 SHORT CHIP 0
JR1686 1-216-296-11 SHORT CHIP 0
JR1687 1-216-296-11 SHORT CHIP 0
JR1688 1-216-296-11 SHORT CHIP 0
JR1689 1-216-296-11 SHORT CHIP 0
JR1690 1-216-296-11 SHORT CHIP 0
JR1691 1-216-296-11 SHORT CHIP 0
JR1692 1-216-296-11 SHORT CHIP 0
JR1693 1-216-296-11 SHORT CHIP 0
JR1694 1-216-296-11 SHORT CHIP 0
JR1695 1-216-296-11 SHORT CHIP 0
JR1696 1-216-296-11 SHORT CHIP 0
JR1697 1-216-296-11 SHORT CHIP 0
JR1698 1-216-296-11 SHORT CHIP 0
JR1699 1-216-296-11 SHORT CHIP 0
< SWITCH >
S1001 1-762-875-21 SWITCH, TACTILE (DJ EFFECT GUITAR)
S1002 1-762-875-21 SWITCH, TACTILE (VOCAL FADER)
S1003 1-762-875-21 SWITCH, TACTILE (
+ )
S1004 1-762-875-21 SWITCH, TACTILE (
―)
S1005 1-762-875-21 SWITCH, TACTILE (Z)
S1006
1-762-875-21 SWITCH, TACTILE (
TUNING + >)
S1007 1-762-875-21 SWITCH, TACTILE (
TUNING ― .)
S1008 1-762-875-21 SWITCH, TACTILE (ENTER)
S1009 1-762-875-21 SWITCH, TACTILE (FIESTA)
S1014 1-762-875-21 SWITCH, TACTILE (1)
S1015
1-762-875-21 SWITCH, TACTILE (MIC ECHO)
S1016 1-762-875-21 SWITCH, TACTILE (REC TO USB)
S1017 1-762-875-21 SWITCH, TACTILE (MEGA BASS)
S1018 1-762-875-21 SWITCH, TACTILE ( PAIRING BLUETOOTH)
S1019 1-762-875-21 SWITCH, TACTILE (LIGHT MODE)
S1020 1-762-875-21 SWITCH, TACTILE (PARTY LIGHT)
S1021 1-762-875-21 SWITCH, TACTILE (x)
S1022
1-762-875-21 SWITCH, TACTILE (N)
S1025
1-762-875-21 SWITCH, TACTILE (PARTY CHAIN)
S1026 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FUNCTION)
TOP PANEL
S1027 1-762-875-21 SWITCH, TACTILE (FOOTBALL)
S1028 1-762-875-21 SWITCH, TACTILE (DJ EFFECT ISOLATOR)
S1029 1-762-875-21 SWITCH, TACTILE (SOUND FIELD)
S1030 1-762-875-21 SWITCH, TACTILE (DJ EFFECT
SAMPLER
)
S1031 1-762-875-21 SWITCH, TACTILE (DJ EFFECT FLANGER)
S1032 1-762-875-21 SWITCH, TACTILE (DJ EFFECT DJ OFF)
*************************************************************
MISCELLANEOUS
**************
0 51 1-855-340-11 DC FAN
0 101 1-855-340-11 DC FAN (HCDSHAKEX70)
151 1-469-829-11 CORE, FERRITE
152 1-912-091-21 FLEXIBLE FLAT CABLE (19 CORE)
(HCDSHAKEX70)
152 1-912-106-21 FLEXIBLE FLAT CABLE (19 CORE) (SHAKE10/
SHAKE30/HCDSHAKEX10/HCDSHAKEX30)
201 1-912-099-21 FLEXIBLE FLAT CABLE (10 CORE)
202 1-492-699-32 BLUETOOTH MODULE
253 1-457-369-12 CORE, FERRITE
0 254 1-474-694-11 REGULATOR, SWITCHING (SSN-172AD)
(SHAKE10/SHAKE30/HCDSHAKEX10/
HCDSHAKEX30)
0 254 1-474-696-13 REGULATOR, SWITCHING (SSN-171AD)
(HCDSHAKEX70)
0 255 1-844-220-11 AC INLET
305 1-912-105-21 FLEXIBLE FLAT CABLE (25 CORE)
306 1-912-104-21 FLEXIBLE FLAT CABLE (11 CORE)
307 1-912-098-21 FLEXIBLE FLAT CABLE (7 CORE)
308 1-912-101-21 FLEXIBLE FLAT CABLE (6 CORE)
309 8-989-602-00 RC-S730 (WW)
351 A-1896-391-B LOADING COMPLETE ASSY (T)
(including MS-476 board)
0 354 A-2046-956-A SERVICE, OPTICAL DEVICE (7G)
355 1-912-103-21 FLEXIBLE FLAT CABLE (5 CORE)
356 1-912-102-21 FLEXIBLE FLAT CABLE (24 CORE)
Note 2: When the BLUETOOTH MODULE and RC-S730 (WW)
are replaced, refer to “NOTE OF REPLACING
MOTHERBOARD BOARD OR BLUETOOTH MODULE
OR RC-S730 (WW)” on page 7.
Note 1: If fl exible fl at cable is replaced, install it after bending it in
the same form as that before replacement.
Ver. 1.3
