Pin No. Pin Name I/O Description
1 NO-USE - Not used
2 NO-USE - Not used
3 O-RGB-SOUT O Serial data output to RGB driver
4 I-SIRCS I Remote control signal input
5 O-RGB-SCLK O Serial clock output to RGB driver
6 BYTE I External data bus with select input
7 CNVSS I Processor mode switch
8 I-XC-IN I Sub system clock input terminal (32.768kHz)
9 O-XC-OUT I Sub system clock output terminal (32.768kHz)
10 I-RESET I
System reset signal input from the reset signal IC "L": reset
After the power supply rises, "L" is input for few msec and then change to "H".
11 O-XOUT O
Main system clock output terminal (8MHz)
12 VSS I Ground terminal
13 I-XIN I Main system clock input terminal (8MHz)
14 VCC1 I Power supply terminal (+3.3V)
15 NMI I Non-maskable interrupt input terminal
16 I-BT-MUTE I Muting on/off control signal input from Bluetooth section.
17 I-AC_CUT I AC off detection signal input from the reset signal IC "L": AC Cut detected
18 I-NFC-RF-DET I NFC RF signal detection signal input from the NFC section
19
O-PCONT-PSAVE-
PROTECT
O Main power on/off control signal output "H":power on
20 O-DAMP-CLK O Clock to Digital Amp
21 O-BT-ON O Bluetooth on/off control signal output terminal for bluetooth section
22 O-RGB-PWM-CLK O PWM clock signal to RGB driver
23 O-RGB-TRANS-LED O Transfer signal to RGB driver
24 O-FAN-PWM O Fan speed control output signal. "H": High speed
25 O-NFC-SW O NFC standby control output terminal to the NFC section
26 O-FL-BK O Blinking signal to FL CIG
27 I-ST-CLK I Tuner IC: Clock signal for IIC communcation
28 I-ST-DATA I Tuner IC: Data signal for IIC communcation
29 I-FLASH-TXD1 I TxD1 (for Debug) / Flash Write TxD1
30 I-FLASH-RXD1 I RxD2 (for Debug) / Flash Write RxD1
31 I-FLASH-CLK1 I On Chip Debuger / Flash Write CLK1
32 I-BT-CTS/FLASH-RTS1 I CTS signal input from Bluetooth section / Flash Write RTS1
33 O-BT-TXD O TX signal output terminal for Bluetooth section
34 I-BT-RXD I RX input signal from Bluetooth section
35 O-BT-RESET O Reset signal output to Bluetooth section
36 O-BT-RTS O RTS signal output terminal for Bluetooth section
37 O-CLOCK-OUT - Not used
38 I-NFC-IRQ I NFC wireless data receive signal input from the NFC section
39
O-NFC-SEL/EPM
(FLASH RECOVERY)
O NFC data read/write control output terminal to the NFC section/EPM FLASH RECOVER
40 O-NFC-DATA O Two-way data bus with the NFC
41 O-NFC-SPICLK O Serial data transfer clock signal output to the NFC
42 O-ST-CE O Tuner IC: Tuner enable input pin
43 I-ST-RDS I Input for RDS Text Detect Signal (L: RDS Detect)
44
NO-USE/CE
(FLASH RECOVERY)
O Not Used / FLASH RECOVER WRITE CE
45 O-MTK-SDO O Data Out Signal to MTK
46 I-MTK-SDI I Data In Signal from MTK
47 I-MTK-CLK I Clock Signal from MTK
48 O-DSP-RESET
O
DSP reset pin
49 O-FRONT-MUTE O Muting Control Switch for Speaker. "L": mute On
50 O-DIGITAL-SEL O Digital Selector Pin
51 O-ANALOG-ASEL O Multiplexer selector A for Analog input
• IC Pin Function Descriptions
MOTHERBOARD BOARD (8/10) IC11 R5F3650MCDFB (SYSTEM CONTROLLER)
To Next Page
