Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
79
C1359 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1360 1-116-908-21 CERAMIC CHIP 0.22uF 10% 250V
C1361 1-116-908-21 CERAMIC CHIP 0.22uF 10% 250V
C1362 1-116-908-21 CERAMIC CHIP 0.22uF 10% 250V
C1363 1-116-908-21 CERAMIC CHIP 0.22uF 10% 250V
C1366 1-100-565-91 CERAMIC CHIP 0.47uF 10% 35V
C1367 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1368 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1369 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1370 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1371 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1372 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1373 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1374 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1375 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1376 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1377 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1378 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1379 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C1380 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
< CONNECTOR >
CN1 1-779-993-11 PIN, CONNECTOR (PWB) 5P
* CN2 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER L)
CN3 1-774-731-21 PIN, CONNECTOR (PC BOARD) 5P
(FOR SERVICE USE - factory internal use only)
* CN4 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
(LED SPEAKER R)
CN6 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
CN7 1-774-730-21 PIN, CONNECTOR (PC BOARD) 3P
(ANTENNA FM/AM)
CN8 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
CN9 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN10 1-815-762-31 CONNECTOR, FFC/FPC (LIF) 14P
CN11 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN12 1-820-123-51 CONNECTOR, FFC/FPC 25P
CN301 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN305 1-843-557-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN306 1-794-362-51 CONNECTOR, FFC/FPC 5P
CN307 1-573-806-21 PIN, CONNECTOR (1.5MM) (SMD) 6P
CN308 1-691-550-11 PIN, CONNECTOR (1.5MM) (SMD) 3P
CN901 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN1000 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN1001 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
* CN1002 1-564-905-11 PIN, CONNECTOR (3.96mm PITCH) 9P
< DIODE >
D1 6-503-857-01 DI BAW56
D2 6-500-400-01 DIODE BAV99-215
D3 6-500-400-01 DIODE BAV99-215
D4 6-500-400-01 DIODE BAV99-215
D5 6-500-400-01 DIODE BAV99-215
D7 6-502-961-01 DI DA2J10100L
D8 6-502-961-01 DI DA2J10100L
D9 8-719-058-24 DIODE RB501V-40TE-17
D300 6-500-400-01 DIODE BAV99-215
D305 6-500-400-01 DIODE BAV99-215
D306 6-500-400-01 DIODE BAV99-215
D901 8-719-069-29 DIODE RB520S-30FJTE61
D902 8-719-069-29 DIODE RB520S-30FJTE61
D1000 6-503-857-01 DI BAW56
D1001 6-503-857-01 DI BAW56
D1002 6-503-857-01 DI BAW56
D1003 6-503-857-01 DI BAW56
D1004 6-503-857-01 DI BAW56
D1005 6-500-514-01 DIODE BAV70
D1006 6-500-514-01 DIODE BAV70
D1007 6-500-514-01 DIODE BAV70
D1010 8-719-073-35 DIODE RB551V-30TE-17
D1014 6-502-970-01 DI DZ2J068M0L
D1015 6-502-970-01 DI DZ2J068M0L
D1016 6-502-970-01 DI DZ2J068M0L
D1017 6-502-970-01 DI DZ2J068M0L
D1018 6-502-974-01 DI DZ2J140M0L
D1019 6-503-026-01 DI DZ2J120M0L
D1020 6-503-026-01 DI DZ2J120M0L
D1023 6-503-042-01 DI DZ2J330M0L
D1024 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1025 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1026 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1027 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1028 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1029 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1030 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1031 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1032 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1033 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1034 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1035 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D1041 6-503-026-01 DI DZ2J120M0L
D1042 6-502-976-01 DI DZ2J150M0L
D1055 6-502-974-01 DI DZ2J140M0L
D1056 6-503-042-01 DI DZ2J330M0L
D1057 6-503-017-01 DI DZ2J075M0L
D1058 6-503-017-01 DI DZ2J075M0L
< TERMINAL, LUG >
* ET1 1-780-408-11 TERMINAL, LUG
* ET2 1-780-408-11 TERMINAL, LUG
* ET5 1-780-408-11 TERMINAL, LUG
* ET6 1-780-408-11 TERMINAL, LUG
* ET1000 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB301 1-216-295-91 SHORT CHIP 0
FB902 1-216-295-91 SHORT CHIP 0
< IC >
IC1 6-719-567-01 IC MM1839A40NRE
IC2 6-718-378-01
IC BU4829F-TR
IC3 6-720-234-01 IC RN5B801-0002
IC4 6-718-293-01 IC BA17809FP-E2
IC5 6-715-134-01 IC MM3404A33URE
IC6 6-716-554-21 IC BD9329AEFJ-BZSE2
IC7 6-716-554-21 IC BD9329AEFJ-BZSE2
IC8 6-716-554-21 IC BD9329AEFJ-BZSE2
* IC9 6-720-237-01 IC USX2064-AEZG-TR
IC10 6-717-138-01 IC KIA7805AF-RTF/PW
IC11 A-1946-402-A IC R5F3650MCDFB (for SERVICE)
IC12 6-718-580-01 IC BA2903FV-E2
MOTHERBOARD
Ver. 1.2
