Sony HCD-SHAKE7 - Electrical Parts List - Motherboard ICs and Transistors; Motherboard ICs and Transistors List (Part 1)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
80
IC13 8-759-909-71 IC BA4558F
IC14 6-719-142-01 IC TC62D723FNG
IC302 6-712-033-01 IC MM1701CHBE
IC304 (Not supplied) IC EM638165 TSB-6G
IC305 (Not supplied) IC W25Q16CVSSIG-R
IC306 (Not supplied) IC CXD90013R
IC651 6-705-973-01 IC PCM1754DBQR
IC652 6-705-973-01 IC PCM1754DBQR
IC653 6-707-800-01 IC SRC4182
IC654 6-710-554-01 IC PCM1808PWR
IC655 6-710-554-01 IC PCM1808PWR
IC656 6-716-697-01 IC TAS3108DCPR
IC658 8-759-909-71 IC BA4558F
IC660 8-759-909-71 IC BA4558F
IC661 8-759-596-39 IC SN74LV4052APWR
IC664 8-759-680-48 IC TC7WH157FK
IC901 6-715-874-01 IC MM3464A33NRE
IC902 (Not supplied) IC AM5890S
IC1000 6-720-389-01 IC IRS2092STRPBF-CU
IC1001 6-720-389-01 IC IRS2092STRPBF-CU
IC1002 6-720-389-01 IC IRS2092STRPBF-CU
IC1003 6-720-389-01 IC IRS2092STRPBF-CU
IC1004 6-720-389-01 IC IRS2092STRPBF-CU
IC1005 6-720-389-01 IC IRS2092STRPBF-CU
IC1006 6-717-138-01 IC KIA7805AF-RTF/PW
IC1007 6-717-136-01 IC KIA7905F-RTF/PW
IC1008 6-717-488-01 IC BA4580RF-E2
IC1010 8-759-700-09 IC NJM2043M-D
IC1011 8-759-700-09 IC NJM2043M-D
IC1012 8-759-700-09 IC NJM2043M-D
IC1014 6-717-191-01 IC KIA7812AF-RTF/PW
IC1015 6-717-191-01 IC KIA7812AF-RTF/PW
IC1016 6-717-191-01 IC KIA7812AF-RTF/PW
< JACK >
J651 1-794-981-1
1 JACK, PIN 4P
(AUDIO IN TV/DVD/SAT L/R, AUDIO IN PC/GAME
L/R)
< COIL >
L1 1-469-187-21 INDUCTOR 68nH
L2 1-469-187-21 INDUCTOR 68nH
L3 1-457-998-11 COIL, AM ANTENNA
L5 1-414-576-41 INDUCTOR 47nH
L6 1-414-455-11 INDUCTOR 2.2nH
L8 1-481-903-11 INDUCTOR 33uH
L10 1-481-903-11 INDUCTOR 33uH
L12 1-481-903-11 INDUCTOR 33uH
L13 1-481-903-11 INDUCTOR 33uH
L14 1-481-903-11 INDUCTOR 33uH
L15 1-481-903-11 INDUCTOR 33uH
L1000 1-400-922-11 INDUCTOR 220uH
L1007 1-481-819-11 INDUCTOR 22uH
L1008 1-481-819-11 INDUCTOR 22uH
L1009 1-481-819-11 INDUCTOR 22uH
L1010 1-481-819-11 INDUCTOR 22uH
L1011 1-481-819-11 INDUCTOR 22uH
L1012 1-481-819-11 INDUCTOR 22uH
< TRANSISTOR >
Q1 6-551-728-01 TRANSISTOR 2SB1710TL
Q2 6-550-363-01 TRANSISTOR 2SB1690KT146
Q3 6-550-363-01 TRANSISTOR 2SB1690KT146
Q4 6-550-363-01 TRANSISTOR 2SB1690KT146
Q5 6-550-987-01 TR RN1911
Q6 6-552-922-01 TR LTA014EUBFS8TL
Q8 6-551-728-01 TRANSISTOR 2SB1710TL
Q9 6-551-728-01 TRANSISTOR 2SB1710TL
Q12 6-552-936-01 TR LTC014EUBFS8TL
Q14 6-552-936-01 TR LTC014EUBFS8TL
Q15 6-552-936-01 TR LTC014EUBFS8TL
Q16 6-552-941-01 TR LTC023JUBFS8TL
Q17 6-552-936-01 TR LTC014EUBFS8TL
Q18 6-552-936-01 TR LTC014EUBFS8TL
Q652 6-550-978-01 TR RN1902
Q901 6-551-120-01 TRANSISTOR 2SA2119K
Q902 6-551-120-01 TRANSISTOR 2SA2119K
Q1000 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1004 6-553-266-01 TR 2PD601ART
Q1005 6-553-266-01 TR 2PD601ART
Q1007 8-729-924-99 TRANSISTOR 2SC3722K-E
* Q1009 6-551-959-01 TR IMX25T110
Q1010 8-729-427-72 TRANSISTOR XP4501
Q1011 8-729-427-72 TRANSISTOR XP4501
Q1012 8-729-427-72 TRANSISTOR XP4501
Q1013 8-729-427-72 TRANSISTOR XP4501
Q1014 8-729-427-72 TRANSISTOR XP4501
Q1015 8-729-427-72 TRANSISTOR XP4501
Q1016 6-550-978-01 TR RN1902
Q1017 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q1019 6-552-891-01 TR LSAR523UBFS8TL
Q1020 6-552-891-01 TR LSAR523UBFS8TL
Q1021 6-552-891-01 TR LSAR523UBFS8TL
Q1022 6-552-891-01 TR LSAR523UBFS8TL
Q1023 6-552-891-01 TR LSAR523UBFS8TL
Q1024 6-552-891-01 TR LSAR523UBFS8TL
Q1025 6-552-891-01 TR LSAR523UBFS8TL
Q1026 6-552-891-01 TR LSAR523UBFS8TL
Q1027 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q1029 6-552-746-01 TR DSA700300L
Q1030 6-552-746-01 TR DSA700300L
Q1032 6-550-978-01 TR RN1902
Q1033 6-552-698-01 TR IRF6775MTR1PBF
Q1034 6-552-698-01 TR IRF6775MTR1PBF
Q1035 6-552-698-01 TR IRF6775MTR1PBF
Q1036 6-552-698-01 TR IRF6775MTR1PBF
Q1037 6-552-698-01 TR IRF6775MTR1PBF
Q1038 6-552-698-01 TR IRF6775MTR1PBF
Q1039 6-552-698-01 TR IRF6775MTR1PBF
Q1040 6-552-698-01 TR IRF6775MTR1PBF
Q1041 6-552-698-01 TR IRF6775MTR1PBF
Q1042 6-552-698-01 TR IRF6775MTR1PBF
Q1043 6-552-698-01 TR IRF6775MTR1PBF
Q1044 6-552-698-01 TR IRF6775MTR1PBF
* Q1045 6-551-959-01 TR IMX25T110
Q1046 6-552-922-01 TR LTA014EUBFS8TL
Q1047 6-552-936-01 TR LTC014EUBFS8TL
Q1048 6-552-936-01 TR LTC014EUBFS8TL
Q1049 6-552-936-01 TR LTC014EUBFS8TL
MOTHERBOARD
Note: IC304, IC305, IC306 and IC902 on the MOTHERBOARD
board cannot exchange with single. When these parts on
the MOTHERBOARD board are damaged, exchange the
entire mounted board.
Ver. 1.2
