Sony HCD-SHAKE7 - Electrical Parts List - Motherboard Transistors and Resistors; Motherboard Transistors and Resistors List (Part 1)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
81
Q1050 6-552-891-01 TR LSAR523UBFS8TL
Q1051 6-552-892-01 TR LSCR523UBFS8TL
Q1052 6-553-266-01 TR 2PD601ART
Q1055 6-553-266-01 TR 2PD601ART
Q1057 6-552-892-01 TR LSCR523UBFS8TL
Q1058 6-552-746-01 TR DSA700300L
< RESISTOR >
R1 1-216-295-91 SHORT CHIP 0
R2 1-216-296-11 SHORT CHIP 0
R3 1-216-295-91 SHORT CHIP 0
R4 1-216-295-91 SHORT CHIP 0
R5 1-216-295-91 SHORT CHIP 0
R6 1-216-295-91 SHORT CHIP 0
R7 1-216-295-91 SHORT CHIP 0
R11 1-216-809-11 METAL CHIP 100 5% 1/10W
R12 1-216-809-11 METAL CHIP 100 5% 1/10W
R13 1-216-809-11 METAL CHIP 100 5% 1/10W
R14 1-216-809-11 METAL CHIP 100 5% 1/10W
R15 1-216-809-11 METAL CHIP 100 5% 1/10W
R16 1-216-809-11 METAL CHIP 100 5% 1/10W
R17 1-216-809-11 METAL CHIP 100 5% 1/10W
R20 1-218-941-81 METAL CHIP 100 5% 1/16W
R21 1-218-941-81 METAL CHIP 100 5% 1/16W
R22 1-218-941-81 METAL CHIP 100 5% 1/16W
R24 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-809-11 METAL CHIP 100 5% 1/10W
R27 1-216-809-11 METAL CHIP 100 5% 1/10W
R31 1-218-965-11 METAL CHIP 10K 5% 1/16W
R32 1-216-864-11 SHORT CHIP 0
R33 1-216-864-11 SHORT CHIP 0
R34 1-218-941-81 METAL CHIP 100 5% 1/16W
R35 1-216-821-11 METAL CHIP 1K 5% 1/10W
R36 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R37 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R38 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R39 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R40 1-218-949-11 METAL CHIP 470 5% 1/16W
R41 1-216-841-11 METAL CHIP 47K 5% 1/10W
R43 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R44 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
R45 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R46 1-218-929-11 METAL CHIP 10 5% 1/16W
R47 1-218-929-11 METAL CHIP 10 5% 1/16W
R48 1-218-929-11 METAL CHIP 10 5% 1/16W
R49 1-218-933-11 METAL CHIP 22 5% 1/16W
R50 1-218-933-11 METAL CHIP 22 5% 1/16W
R51 1-218-933-11 METAL CHIP 22 5% 1/16W
R52 1-218-933-11 METAL CHIP 22 5% 1/16W
R53 1-218-933-11 METAL CHIP 22 5% 1/16W
R54 1-218-941-81 METAL CHIP 100 5% 1/16W
R55 1-218-941-81 METAL CHIP 100 5% 1/16W
R57 1-218-949-11 METAL CHIP 470 5% 1/16W
R58 1-218-941-81 METAL CHIP 100 5% 1/16W
R59 1-218-941-81 METAL CHIP 100 5% 1/16W
R61 1-218-941-81 METAL CHIP 100 5% 1/16W
R62 1-218-941-81 METAL CHIP 100 5% 1/16W
R63 1-218-941-81 METAL CHIP 100 5% 1/16W
R64 1-218-941-81 METAL CHIP 100 5% 1/16W
R65 1-218-941-81 METAL CHIP 100 5% 1/16W
R66 1-218-965-11 METAL CHIP 10K 5% 1/16W
R67 1-218-941-81 METAL CHIP 100 5% 1/16W
R68 1-218-941-81 METAL CHIP 100 5% 1/16W
R69 1-218-941-81 METAL CHIP 100 5% 1/16W
R70 1-218-941-81 METAL CHIP 100 5% 1/16W
0 R71 1-218-941-81 METAL CHIP 100 5% 1/16W
0 R72 1-218-967-11 METAL CHIP 15K 5% 1/16W
R75 1-218-941-81 METAL CHIP 100 5% 1/16W
R76 1-218-941-81 METAL CHIP 100 5% 1/16W
R77 1-218-941-81 METAL CHIP 100 5% 1/16W
R78 1-218-941-81 METAL CHIP 100 5% 1/16W
R79 1-218-941-81 METAL CHIP 100 5% 1/16W
R81 1-216-864-11 SHORT CHIP 0
R82 1-218-941-81 METAL CHIP 100 5% 1/16W
R83 1-218-941-81 METAL CHIP 100 5% 1/16W
R84 1-218-941-81 METAL CHIP 100 5% 1/16W
R85 1-218-941-81 METAL CHIP 100 5% 1/16W
R86 1-218-941-81 METAL CHIP 100 5% 1/16W
R87 1-218-941-81 METAL CHIP 100 5% 1/16W
R88 1-218-941-81 METAL CHIP 100 5% 1/16W
R89 1-218-941-81 METAL CHIP 100 5% 1/16W
R90 1-218-941-81 METAL CHIP 100 5% 1/16W
R91 1-218-941-81 METAL CHIP 100 5% 1/16W
R92 1-218-941-81 METAL CHIP 100 5% 1/16W
R94 1-218-941-81 METAL CHIP 100 5% 1/16W
R95 1-218-941-81 METAL CHIP 100 5% 1/16W
R96 1-218-941-81 METAL CHIP 100 5% 1/16W
R97 1-216-864-11 SHORT CHIP 0
R98 1-218-941-81 METAL CHIP 100 5% 1/16W
R99 1-218-941-81 METAL CHIP 100 5% 1/16W
R100 1-218-941-81 METAL CHIP 100 5% 1/16W
R101 1-218-941-81 METAL CHIP 100 5% 1/16W
R102 1-218-941-81 METAL CHIP 100 5% 1/16W
R103 1-218-941-81 METAL CHIP 100 5% 1/16W
R104 1-218-941-81 METAL CHIP 100 5% 1/16W
R105 1-216-864-11 SHORT CHIP 0
R106 1-218-947-11 METAL CHIP 330 5% 1/16W
R107 1-218-949-11 METAL CHIP 470 5% 1/16W
R108 1-218-949-11 METAL CHIP 470 5% 1/16W
R109 1-218-949-11 METAL CHIP 470 5% 1/16W
R110 1-218-949-11 METAL CHIP 470 5% 1/16W
R111 1-218-953-11 METAL CHIP 1K 5% 1/16W
R112 1-218-937-11 METAL CHIP 47 5% 1/16W
R113 1-218-953-11 METAL CHIP 1K 5% 1/16W
R114 1-218-953-11 METAL CHIP 1K 5% 1/16W
R115 1-218-953-11 METAL CHIP 1K 5% 1/16W
R116 1-218-953-11 METAL CHIP 1K 5% 1/16W
R117 1-218-953-11 METAL CHIP 1K 5% 1/16W
R120 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R121 1-216-864-11 SHORT CHIP 0
R122 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R123 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R125 1-218-965-11 METAL CHIP 10K 5% 1/16W
R126 1-218-965-11 METAL CHIP 10K 5% 1/16W
R127 1-218-965-11 METAL CHIP 10K 5% 1/16W
R128 1-218-965-11 METAL CHIP 10K 5% 1/16W
R129 1-218-965-11 METAL CHIP 10K 5% 1/16W
R130 1-218-965-11 METAL CHIP 10K 5% 1/16W
R132 1-218-965-11 METAL CHIP 10K 5% 1/16W
R133 1-218-965-11 METAL CHIP 10K 5% 1/16W
MOTHERBOARD
Ver. 1.2
