Sony HCD-SHAKE7 - Electrical Parts List - Miscellaneous Boards; MS-476, RGB, USB Boards List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
87
R1412 1-216-851-11 METAL CHIP 330K 5% 1/10W
R1415 1-216-295-91 SHORT CHIP 0
R1418 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R1419 1-216-796-11 METAL CHIP 8.2 5% 1/10W
R1420 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1421 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1422 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1423 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1424 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1428 1-257-362-21 METAL CHIP 1 5% 1/2W
R1430 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1431 1-257-362-21 METAL CHIP 1 5% 1/2W
R1433 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1434 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R1435 1-216-864-11 SHORT CHIP 0
R1437 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1440 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1443 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1446 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1449 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1452 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R1454 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1455 1-216-844-11 METAL CHIP 82K 5% 1/10W
R1456 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1457 1-216-844-11 METAL CHIP 82K 5% 1/10W
R1458 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1459 1-216-844-11 METAL CHIP 82K 5% 1/10W
R1460 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1461 1-216-844-11 METAL CHIP 82K 5% 1/10W
R1462 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1463 1-216-844-11 METAL CHIP 82K 5% 1/10W
R1464 1-216-843-11 METAL CHIP 68K 5% 1/10W
R1465 1-216-844-11 METAL CHIP 82K 5% 1/10W
R1466 1-216-864-11 SHORT CHIP 0
R1467 1-216-864-11 SHORT CHIP 0
R1468 1-216-864-11 SHORT CHIP 0
R1469 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1470 1-216-864-11 SHORT CHIP 0
R1471 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1472 1-216-296-11 SHORT CHIP 0
R1473 1-216-296-11 SHORT CHIP 0
R1474 1-216-296-11 SHORT CHIP 0
R1475 1-216-296-11 SHORT CHIP 0
R1476 1-216-296-11 SHORT CHIP 0
R1477 1-216-296-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB301 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB302 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB303 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB304 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB305 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB306 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB307 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB308 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB309 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< TERMINAL >
TB1000 1-854-003-21 TERMINAL BOARD
(TWEETERS/WOOFERS IMPEDANCE USE 4Ω
R/L)
TB1001 1-780-932-11 TERMINAL BOARD
(MID SPEAKERS IMPEDANCE USE 5Ω R/L)
TB1002 1-854-001-21 TERMINAL BOARD (SPEAKER)
(SUBWOOFERS IMPEDANCE USE 4Ω R/L)
< THERMISTOR >
0 TH1000 1-804-045-11 THERMISTOR
0 TH1001 1-804-045-11 THERMISTOR
0 TH1002 1-804-045-11 THERMISTOR
0 TH1003 1-804-045-11 THERMISTOR
0 TH1004 1-804-045-11 THERMISTOR
0 TH1005 1-804-045-11 THERMISTOR
< VIBRATOR >
X1 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X2 1-814-306-11 VIBRATOR, CRYSTAL (24MHz)
X3 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
X4 1-814-446-11 QUARTZ CRYSTAL UNIT (8MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz)
X651 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288MHz)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire LOADING ASSY (T).
*************************************************************
RGB BAR_L BOARD
****************
< CONNECTOR >
CN1901 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
< DIODE >
D1901 6-503-944-51 DI SMLVN6RGB1U17QYB
D1903 6-503-944-51 DI SMLVN6RGB1U17QYB
D1905 6-503-944-51 DI SMLVN6RGB1U17QYB
*************************************************************
RGB BAR_R BOARD
****************
< CONNECTOR >
CN1902 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
< DIODE >
D1902 6-503-944-51 DI SMLVN6RGB1U17QYB
D1904 6-503-944-51 DI SMLVN6RGB1U17QYB
D1906 6-503-944-51 DI SMLVN6RGB1U17QYB
*************************************************************
0 A-1920-100-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C2202 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C2204 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
MOTHERBOARD
MS-476
RGB BAR
_
L
RGB BAR
_
R USB
Ver. 1.2
