Sony HCD-SHAKE7 - Electrical Parts List - USB and Volume Board; USB and Volume Board Components List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE7
88
C2206 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2207 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C2208 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2209 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2211 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2212 1-126-382-11 ELECT 100uF 20% 16V
C2213 1-126-382-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN2201 1-819-866-11 USB CONNECTOR (A) (PLAY A
5V 500mA)
CN2202 1-819-866-11 USB CONNECTOR (A)
(REC/PLAY B 5V 500mA)
CN2203 1-779-544-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< DIODE >
D2201 6-503-388-01 DI 1L0352B13F0MIT02
D2202 6-503-388-01 DI 1L0352B13F0MIT02
D2203 6-500-400-01 DIODE BAV99-215
D2204 6-500-400-01 DIODE BAV99-215
D2205 6-500-400-01 DIODE BAV99-215
D2206 6-500-400-01 DIODE BAV99-215
D2207 6-500-400-01 DIODE BAV99-215
D2208 6-500-400-01 DIODE BAV99-215
D2210 6-502-970-01 DI DZ2J068M0L
D2212 6-502-970-01 DI DZ2J068M0L
D2213 6-502-970-01 DI DZ2J068M0L
D2214 6-502-970-01 DI DZ2J068M0L
D2215 6-502-970-01 DI DZ2J068M0L
D2216 6-502-970-01 DI DZ2J068M0L
< IC >
IC2201 6-600-766-01 IC PNA4823M01S0
< JUMPER RESISTOR >
JR2200 1-216-296-11 SHORT CHIP 0
JR2201 1-216-296-11 SHORT CHIP 0
JR2202 1-216-295-91 SHORT CHIP 0
JR2203 1-216-296-11 SHORT CHIP 0
JR2204 1-216-296-11 SHORT CHIP 0
JR2205 1-216-296-11 SHORT CHIP 0
JR2206 1-216-296-11 SHORT CHIP 0
JR2207 1-216-296-11 SHORT CHIP 0
JR2208 1-216-296-11 SHORT CHIP 0
JR2209 1-216-864-11 SHORT CHIP 0
JR2210 1-216-296-11 SHORT CHIP 0
JR2211 1-216-296-11 SHORT CHIP 0
JR2212 1-216-296-11 SHORT CHIP 0
JR2213 1-216-295-91 SHORT CHIP 0
JR2214 1-216-296-11 SHORT CHIP 0
JR2215 1-216-296-11 SHORT CHIP 0
JR2216 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R2201 1-216-801-11 METAL CHIP 22 5% 1/10W
R2202 1-216-819-11 METAL CHIP 680 5% 1/10W
R2203 1-216-807-11 METAL CHIP 68 5% 1/10W
R2204 1-216-807-11 METAL CHIP 68 5% 1/10W
< SWITCH >
S2201 1-762-875-21 SWITCH, TACTILE (REC TO USB)
S2202 1-762-875-21 SWITCH, TACTILE (ENTER)
*************************************************************
VOLUME BOARD
*************
< CAPACITOR >
C2601 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2602 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C2603 1-137-765-21 ELECT CHIP 47uF 20% 16V
C2604 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2607 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2608 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2609 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2610 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2611 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2612 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2613 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2614 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2615 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2616 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2617 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2618 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2619 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2620 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2621 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2622 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2623 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2624 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C2625 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2626 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2627 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2628 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2629 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2630 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2631 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2632 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2633 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2634 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2635 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2636 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2637 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2638 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN2601 1-821-771-51 CONNECTOR, FFC/FPC 17P
CN2602 1-785-470-51 CONNECTOR, FFC/FPC 7P
CN2603 1-778-795-21 PIN, CONNECTOR (PC BOARD) 9P
< DIODE >
D2601 6-503-944-51 DI SMLVN6RGB1U17QYB
D2602 6-503-944-51 DI SMLVN6RGB1U17QYB
D2603 6-503-944-51 DI SMLVN6RGB1U17QYB
D2604 6-503-944-51 DI SMLVN6RGB1U17QYB
D2605 6-503-944-51 DI SMLVN6RGB1U17QYB
D2606 6-500-400-01 DIODE BAV99-215
D2607 6-500-400-01 DIODE BAV99-215
D2608 6-500-400-01 DIODE BAV99-215
D2609 6-500-400-01 DIODE BAV99-215
D2610 6-500-400-01 DIODE BAV99-215
VOLUME
USB
Ver. 1.2
