HCD-SR4W
Pin No. Pin Name I/O Description
92 SIRCS I Remote control signal input
93 WAKE I
System wake up signal input by pressing a key on the front panel or remote
commander or disc insert detect switch
94 RDS-CLK I RDS serial data transfer clock signal input from the RDS decoder
95 AV-SEL0 O Audio/video selection signal output
96 AV-SEL1 O Audio/video selection signal output
97 DF-SW O selection signal output to the digital audio processor
98 DF-SYNC O Sync signal output to the digital audio processor
99, 100 NC — Not used (fixed at “L”)
