6-11. PRINTED WIRING BOARD — DMB08 BOARD (SIDE A) —
• See page 28 for Circuit Boards Location. :Uses unleaded solder.
IC401
IC301
IC901
IC813
IC612
IC605
IC606
IC801
IC607
IC701
IC206
IC402
D
DDCON
BOARD
CN800
(Page 60)
FOR
CHECK
FOR
CHECK
A
RF
BOARD
CN002
(Page 36)
F
IO
BOARD
CN201
(Page 57)
E
IO
BOARD
CN601
(Page 57)
SWITCHING
REGULATOR
CN8
C
AMP
BOARD
CN301
(Page 52)
B
AMP
BOARD
CN302
(Page 52)
G
DRIVER
BOARD
CN701
(Page 38)
12
A
B
C
D
E
F
3456789
CN010
Y
DIAT TRANSMIT BOARD
CN801
(Page 62)
• Semiconductor Location
Ref. No. Location
D900 C-2
D901 C-4
IC206 D-5
IC301 C-2
IC401 D-2
IC402 D-2
IC605 C-8
Ref. No. Location
IC606 C-7
IC607 B-7
IC612 B-6
IC701 D-4
IC801 B-5
IC813 C-4
IC901 B-2
