Sony HCD-SR4W - Printed Wiring Board - AMP Board (Side A)

5151
HCD-SR4W
HCD-SR4W
6-23. PRINTED WIRING BOARD — AMP BOARD (SIDE A) —
• See page 28 for Circuit Boards Location. :Uses unleaded solder.
IC303
IC101IC102IC105IC106IC107
IC305
IC108
IC110
IC301
12
A
B
C
D
E
F
34567
(22)
22
R138
R146
• Semiconductor
Location
Ref. No. Location
IC101 D-6
IC102 D-5
IC105 D-3
IC106 D-2
IC107 D-1
IC108 E-4
IC110 E-2
IC301 E-6
IC303 C-7
IC305 E-5
Q102 B-6
Q104 B-7
Q110 B-3
Q112 B-3
Q114 B-1
Q301 E-1
Q304 C-1
