Sony HCD-SR4W - Printed Wiring Board - DDCON Board

6060
HCD-SR4W
HCD-SR4W
6-32. PRINTED WIRING BOARD — DDCON BOARD —
• See page 28 for Circuit Boards Location. :Uses unleaded solder.
O
FL
BOARD
CN803
(Page 66)
14
15
D
DMB08
BOARD
CN005
(Page 39)
12
A
B
C
D
34567
• Semiconductor
Location
Ref. No. Location
D810 C-5
D811 C-5
D813 C-5
D814 C-5
D815 C-3
Q802 C-6
