124
HCD-SR4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R959 1-218-990-11 SHORT CHIP 0
R960 1-218-965-11 RES-CHIP 10K 5% 1/16W
R961 1-218-965-11 RES-CHIP 10K 5% 1/16W
R962 1-218-965-11 RES-CHIP 10K 5% 1/16W
R963 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
(RU)
R963 1-218-965-11 RES-CHIP 10K 5% 1/16W
(AEP, UK, KR, CH, MX, E41)
R963 1-218-973-11 RES-CHIP 47K 5% 1/16W
(EA, AUS)
R964 1-218-977-11 RES-CHIP 100K 5% 1/16W
R967 1-218-941-81 RES-CHIP 100 5% 1/16W
R968 1-218-941-81 RES-CHIP 100 5% 1/16W
R971 1-218-965-11 RES-CHIP 10K 5% 1/16W
R972 1-218-965-11 RES-CHIP 10K 5% 1/16W
R977 1-218-969-11 RES-CHIP 22K 5% 1/16W
R978 1-218-953-11 RES-CHIP 1K 5% 1/16W
R979 1-218-973-11 RES-CHIP 47K 5% 1/16W
R980 1-218-973-11 RES-CHIP 47K 5% 1/16W
R981 1-218-965-11 RES-CHIP 10K 5% 1/16W
(EA, HK, SP, KR)
R981 1-218-967-11 RES-CHIP 15K 5% 1/16W
(AUS)
R981 1-218-973-11 RES-CHIP 47K 5% 1/16W
(RU)
R985 1-218-985-11 RES-CHIP 470K 5% 1/16W
R986 1-218-973-11 RES-CHIP 47K 5% 1/16W
R987 1-218-973-11 RES-CHIP 47K 5% 1/16W
R989 1-218-990-11 SHORT CHIP 0
R990 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R991 1-218-965-11 RES-CHIP 10K 5% 1/16W
R992 1-218-965-11 RES-CHIP 10K 5% 1/16W
R994 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R995 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R996 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R997 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R998 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
< VIBRATOR >
X301 1-795-375-11 VIBRATOR, CERAMIC 20MHz
X302 1-795-630-11 VIBRATOR, CRYSTAL 27MHz
X600 1-781-465-21 VIBRATOR, CRYSTAL 12.288MHz
X601 1-813-325-11 VIBRATOR, CRYSTAL 13.9MHz
X901 1-795-375-11 VIBRATOR, CERAMIC 20MHz
************************************************************
1-688-337-11 DRIVER BOARD
*************
< CAPACITOR >
C705 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C711 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE)7P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-T-77-4.7C
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W F
R702 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-762-951-13 SWITCH, PUSH
S702 1-762-951-13 SWITCH, PUSH
S703 1-762-951-13 SWITCH, PUSH
************************************************************
A-4751-729-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C805 1-126-795-11 ELECT 10uF 20% 50V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C841 1-117-370-11 CERAMIC CHIP 10uF 10V
C842 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C843 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C846 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C847 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C848 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C849 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C850 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
< CONNECTOR >
CN803 1-779-554-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN812 1-784-859-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< FERRITE BEAD >
FB005 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB807 1-414-813-11 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL801 1-519-759-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-826-33 IC NJL73H400A (
)
IC803 6-705-899-01 IC ML9208-03MBZ03B
< TRANSISTOR >
Q810 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
< RESISTOR >
R828 1-216-864-11 SHORT CHIP 0
R840 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R843 1-216-833-11 METAL CHIP 10K 5% 1/10W
R844 1-216-809-11 METAL CHIP 100 5% 1/10W
R849 1-216-833-11 METAL CHIP 10K 5% 1/10W
R851 1-216-809-11 METAL CHIP 100 5% 1/10W
R852 1-216-805-11 METAL CHIP 47 5% 1/10W
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R877 1-216-821-11 METAL CHIP 1K 5% 1/10W
R878 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
