HCD-SR4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R007 1-216-803-11 METAL CHIP 33 5% 1/10W
R008 1-216-803-11 METAL CHIP 33 5% 1/10W
R009 1-216-841-11 METAL CHIP 47K 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-864-11 METAL CHIP 0 5% 1/10W
R012 1-216-864-11 METAL CHIP 0 5% 1/10W
R013 1-216-864-11 METAL CHIP 0 5% 1/10W
R014 1-216-864-11 METAL CHIP 0 5% 1/10W
R015 1-216-864-11 METAL CHIP 0 5% 1/10W
R016 1-216-864-11 METAL CHIP 0 5% 1/10W
R017 1-216-864-11 METAL CHIP 0 5% 1/10W
R018 1-216-864-11 METAL CHIP 0 5% 1/10W
R019 1-216-864-11 METAL CHIP 0 5% 1/10W
R020 1-216-864-11 METAL CHIP 0 5% 1/10W
R021 1-216-864-11 METAL CHIP 0 5% 1/10W
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 METAL CHIP 0 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/16W
R027 1-216-864-11 METAL CHIP 0 5% 1/10W
R028 1-216-864-11 METAL CHIP 0 5% 1/10W
R029 1-216-864-11 METAL CHIP 0 5% 1/10W
R032 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-864-11 METAL CHIP 0 5% 1/10W
R034 1-219-570-11 RES-CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/10W
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
SCART BOARD (AEP, UK, RU)
************************
< CAPACITOR >
C230 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU)
C231 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP, UK, RU)
< JACK >
J203 1-815-911-11 CONNECTOR, SQUARE TYPE 21P
(EURO AV T OUTPUT (TO TV))
(AEP, UK, RU)
************************************************************
1-861-987-12 SONY LAMP BOARD
****************
< CAPACITOR >
C862 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C863 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN806 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D819 6-500-929-01 DIODE SML-512WBCW1AR (SONY)
D821 6-500-929-01 DIODE SML-512WBCW1AR (SONY)
< RESISTOR >
R846 1-216-809-11 METAL CHIP 100 5% 1/10W
R847 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
MISCELLANEOUS
**************
5 1-828-962-11 WIRE (FLAT TYPE) (11 CORE)
08 1-696-169-51 CORD, POWER (AEP, UK, RU, HK, SP, E41)
08 1-696-847-22 CORD, POWER (AUS)
08 1-751-520-21 CORD, POWER (EA)
08 1-769-079-32 CORD, POWER (KR)
08 1-775-789-91 CORD, POWER (MX)
08 1-782-464-22 CORD, POWER (CH)
08 1-827-597-41 CORD, POWER (TW)
9 1-763-861-12 FAN, DC
54 1-829-279-11 FLEXIBLE FLAT CABLE (7 CORE)
63 1-828-350-11 WIRE (FLAT TYPE) (17 CORE)
0105 1-468-838-11 REGULATOR, SWITCHING
108 1-828-339-11 WIRE (FLAT TYPE) (15 CORE)
109 1-828-409-11 WIRE (FLAT TYPE) (29 CORE)
110 1-829-280-11 FLEXIBLE FLAT CABLE (15 CORE)
111 1-828-411-11 WIRE (FLAT TYPE) (29 CORE)
112 1-829-743-11 CABLE, FLEXIBLE FLAT (9 CORE)
113 1-829-281-11 FLEXIBLE FLAT CABLE (17 CORE)
114 1-828-323-11 WIRE (FLAT TYPE) (11 CORE)
602 1-685-250-11 FLEXIBLE BOARD
0605 1-477-263-13 OPTICAL PICK-UP (DBU-1)
M701 X-2021-530-1 MOTOR (PULLEY) ASSY (LOADING)
SCARTRF SONY LAMP
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
