Waveforms
BD SECTION
FL Section
MAIN (2/5) Section
VIDEO SECTION
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed
in each block.)
For schematic diagrams.
Note:
All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
All resistors are in and
1
/
4
W or less unless otherwise
specified.
¢
: internal component.
C : panel designation.
For printed wiring boards.
Note:
X : parts extracted from the component side.
®
: Through hole.
¢
: internal component.
b : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
U : B+ Line.
V : B– Line.
H : adjustment for repair.
Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
Voltages are taken with a VOM (Input impedance 10 M).
Voltage variations may be noted due to normal produc-
tion tolerances.
Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
Circled numbers refer to waveforms.
Signal path.
F : FM
g : VIDEO/MD
E : PB (DECK A)
d : PB (DECK B)
G : REC (DECK B)
J : CD
c : digital out
I : PHONO
o : CD VIDEO
n :Y
m : CHROMA
Abbreviation
IA : Indonesia model
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
TH : Thai model
Indication of transistor
C
These are omitted
EB
Q
C
These are omitted
EB
1.3Vp-p
1
2
3
4
IC101 RFAC
IC101 TE
IC101 FE
IC101 @∞ MDP
APPROX 500mVp-p
2.5V
APPROX 200mVp-p
2.5V
2.6Vp-p
7.5µsec
1
2
IC501 X-OUT
IC501 XC-OUT
16MHz
5.5Vp-p
32.768kHz
5.2Vp-p
1
IC601 &™ X-OUT
12.5MHz
3.4Vp-p
1
IC502 XOUT
2
IC505 &∞ COUT
3
IC505 YOUT
4
IC401 7 COUT
5
IC401 1 YOUT
6
CN301 2 VOUT
!™
IC504 !™
!¡
IC504 6 27M
0
IC504 8 384FS
9
IC509 BCLK
8
IC509 LRCK
7
IC509 1 XT1
4Vp-p
10MHz
H
1Vp-p
H
1Vp-p
2Vp-p
H
2Vp-p
H
H
1.2
Vp-p
27MHz
5.8Vp-p
4.6Vp-p
44.1kHz
4.8Vp-p
2.11MHz
4.8Vp-p
33.8MHz
3.8Vp-p
27MHz
2.8Vp-p
33.8MHz
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
