Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
82
A-4417-554-A JACK BOARD, COMPLETE
********************
< CAPACITOR >
C803 1-162-306-11 CERAMIC 0.01uF 30% 16V
C804 1-162-306-11 CERAMIC 0.01uF 30% 16V
C805 1-126-957-11 ELECT 0.22uF 20% 50V
C807 1-162-294-31 CERAMIC 0.001uF 10% 50V
C808 1-162-294-31 CERAMIC 0.001uF 10% 50V
C809 1-164-159-21 CERAMIC 0.1uF 50V
C810 1-164-159-21 CERAMIC 0.1uF 50V
C856 1-162-294-31 CERAMIC 0.001uF 10% 50V
C857 1-162-286-21 CERAMIC 220PF 10% 50V
C858 1-126-964-11 ELECT 10uF 20% 50V
C859 1-126-961-11 ELECT 2.2uF 20% 50V
C860 1-162-215-31 CERAMIC 47PF 5% 50V
C861 1-162-282-31 CERAMIC 100PF 10% 50V
C862 1-126-961-11 ELECT 2.2uF 20% 50V
C863 1-126-960-11 ELECT 1uF 20% 50V
C864 1-126-964-11 ELECT 10uF 20% 50V
C865 1-126-960-11 ELECT 1uF 20% 50V
C866 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C867 1-162-294-31 CERAMIC 0.001uF 10% 50V
C868 1-136-495-11 FILM 0.068uF 5% 50V
C869 1-126-959-11 ELECT 0.47uF 20% 50V
C870 1-126-959-11 ELECT 0.47uF 20% 50V
C871 1-126-967-11 ELECT 47uF 20% 50V
C872 1-162-306-11 CERAMIC 0.01uF 30% 16V
C873 1-104-664-11 ELECT 47uF 20% 25V
C874 1-136-495-11 FILM 0.068uF 5% 50V
C875 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C876 1-162-294-31 CERAMIC 0.001uF 10% 50V
C877 1-136-167-00 FILM 0.15uF 5% 50V
C878 1-126-960-11 ELECT 1uF 20% 50V
C879 1-161-494-00 CERAMIC 0.022uF 25V
C880 1-126-961-11 ELECT 2.2uF 20% 50V
C882 1-162-290-31 CERAMIC 470PF 10% 50V
C883 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN802 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D851 8-719-200-82 DIODE 11ES2-TA1B
D852 8-719-200-82 DIODE 11ES2-TA1B
D853 8-719-200-82 DIODE 11ES2-TA1B
< EARTH >
* EPT802 1-537-738-21 TERMINAL, EARTH
< FILTER >
FL801 1-424-228-11 FILTER, NOISE
FL802 1-424-228-11 FILTER, NOISE
< IC >
IC850 8-759-634-50 IC M5218AL
IC851 8-759-450-96 IC M65850P
< JACK >
J801 1-770-226-11 JACK (LARGE TYPE)(MIC1)
J802 1-770-226-11 JACK (LARGE TYPE)(MIC2)
J803 1-770-226-11 JACK (LARGE TYPE)(PHONE)
< COIL >
L851 1-410-521-11 INDUCTOR 100uH
< RESISTOR >
R806 1-249-429-11 CARBON 10K 5% 1/4W
R807 1-249-429-11 CARBON 10K 5% 1/4W
R808 1-249-417-11 CARBON 1K 5% 1/4W F
R809 1-249-417-11 CARBON 1K 5% 1/4W F
R810 1-247-807-31 CARBON 100 5% 1/4W
R850 1-247-807-31 CARBON 100 5% 1/4W
R852 1-249-441-11 CARBON 100K 5% 1/4W
R853 1-249-417-11 CARBON 1K 5% 1/4W F
R854 1-249-437-11 CARBON 47K 5% 1/4W
R855 1-249-429-11 CARBON 10K 5% 1/4W
R856 1-247-889-00 CARBON 270K 5% 1/4W
R857 1-247-807-31 CARBON 100 5% 1/4W
R858 1-247-863-91 CARBON 22K 5% 1/4W
R859 1-247-863-91 CARBON 22K 5% 1/4W
R860 1-247-863-91 CARBON 22K 5% 1/4W
R861 1-247-881-00 CARBON 120K 5% 1/4W
R862 1-247-863-91 CARBON 22K 5% 1/4W
R863 1-247-863-91 CARBON 22K 5% 1/4W
R864 1-247-863-91 CARBON 22K 5% 1/4W
R865 1-249-437-11 CARBON 47K 5% 1/4W
R866 1-249-431-11 CARBON 15K 5% 1/4W
R867 1-249-431-11 CARBON 15K 5% 1/4W
< VARIABLE RESISTOR >
RV850 1-225-587-11 RES, VAR, CARBON 50K (MIC-VOL)
RV851 1-225-587-11 RES, VAR, CARBON 50K (ECHO LEVEL)
************************************************************
A-2007-800-A LEAF SW BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77
D1002 8-719-991-33 DIODE 1SS133T-77
< CABLE >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264
JACK LEAF SW
