Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
90
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878AB-TPE2
Q903 8-729-048-52 TRANSISTOR 2SA1932(TP)
Q904 8-729-119-76 TRANSISTOR 2SA1115TP-EF
< RESISTOR >
! R401 1-215-889-00 METAL OXIDE 330 5% 2W F
! R402 1-215-889-00 METAL OXIDE 330 5% 2W F
! R403 1-215-889-00 METAL OXIDE 330 5% 2W F
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-440-11 CARBON 82K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R425 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R430 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-247-863-91 CARBON 22K 5% 1/4W
R435 1-249-425-11 CARBON 4.7K 5% 1/4W F
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-247-863-91 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
R442 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-434-11 CARBON 27K 5% 1/4W
R444 1-249-439-11 CARBON 68K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R450 1-249-437-11 CARBON 47K 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-415-11 CARBON 680 5% 1/4W F
R804 1-249-435-11 CARBON 33K 5% 1/4W
! R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
! R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W F
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-247-863-91 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W F
R818 1-249-417-11 CARBON 1K 5% 1/4W F
R819 1-249-439-11 CARBON 68K 5% 1/4W
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R822 1-247-863-91 CARBON 22K 5% 1/4W
R823 1-247-863-91 CARBON 22K 5% 1/4W
R824 1-249-416-11 CARBON 820 5% 1/4W F
R824 1-249-435-11 CARBON 33K 5% 1/4W
! R825 1-215-891-11 METAL OXIDE 680 5% 2W F
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-419-11 CARBON 1.5K 5% 1/4W F
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
! R839 1-215-877-11 METAL OXIDE 22K 5% 1W F
R840 1-249-402-11 CARBON 56 5% 1/4W F
! R842 1-202-972-61 FUSIBLE 1 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-415-11 CARBON 680 5% 1/4W F
! R855 1-215-891-11 METAL OXIDE 680 5% 2W F
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R868 1-249-417-11 CARBON 1K 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
! R889 1-215-877-11 METAL OXIDE 22K 5% 1W F
! R902 1-215-916-00 METAL OXIDE 680 5% 3W F
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R909 1-247-791-91 CARBON 22 5% 1/4W
< RELAY >
RY401 1-755-168-11 RELAY
RY402 1-515-920-11 RELAY (24V)
RY403 1-515-920-11 RELAY (24V)
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-31 TERMINAL BOARD (SPEAKER) (6P)
(SURROUND SPEAKER)
************************************************************
A-4417-488-A PANEL-VR BOARD, COMPLETE
************************
< CAPACITOR >
C610 1-162-306-11 CERAMIC 0.01uF 30% 16V
C611 1-162-306-11 CERAMIC 0.01uF 30% 16V
C612 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D611 8-719-058-04 DIODE SEL5223S-TP15 (GROOVE)
D612 8-719-058-04 DIODE SEL5223S-TP15 (SUPER WOOFER)
D613 8-719-057-97 DIODE SEL5923A-TP15 (PRO LOGIC)
D614 8-719-057-97 DIODE SEL5923A-TP15 (DVD 5.1CH)
D615 8-719-057-97 DIODE SEL5923A-TP15 (K-CON)
PANEL-VRPA
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
