Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
96
Sony Corporation
Home Audio Company
9-928-954-11
99F1623-1D
Printed in Japan ©1999.6
Published by Quality Assurance Dept.
HCD-VR90AV
R537 1-216-025-91 RES,CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R542 1-216-049-91 RES,CHIP 1K 5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-91 RES,CHIP 100 5% 1/10W
R546 1-216-049-91 RES,CHIP 1K 5% 1/10W
R547 1-216-295-91 SHORT 0
R548 1-216-049-91 RES,CHIP 1K 5% 1/10W
R549 1-216-025-91 RES,CHIP 100 5% 1/10W
R550 1-216-025-91 RES,CHIP 100 5% 1/10W
R551 1-216-025-91 RES,CHIP 100 5% 1/10W
R552 1-216-025-91 RES,CHIP 100 5% 1/10W
R554 1-216-025-91 RES,CHIP 100 5% 1/10W
R555 1-216-121-91 RES,CHIP 1M 5% 1/10W
R556 1-216-025-91 RES,CHIP 100 5% 1/10W
R557 1-216-025-91 RES,CHIP 100 5% 1/10W
R558 1-216-073-00 METAL CHIP 10K 5% 1/10W
R559 1-216-073-00 METAL CHIP 10K 5% 1/10W
R560 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R561 1-216-049-91 RES,CHIP 1K 5% 1/10W
R562 1-216-025-91 RES,CHIP 100 5% 1/10W
R563 1-216-025-91 RES,CHIP 100 5% 1/10W
R564 1-216-025-91 RES,CHIP 100 5% 1/10W
R565 1-216-025-91 RES,CHIP 100 5% 1/10W
R566 1-216-025-91 RES,CHIP 100 5% 1/10W
R567 1-216-073-00 METAL CHIP 10K 5% 1/10W
R568 1-216-073-00 METAL CHIP 10K 5% 1/10W
R569 1-216-073-00 METAL CHIP 10K 5% 1/10W
R572 1-216-073-00 METAL CHIP 10K 5% 1/10W
R573 1-216-073-00 METAL CHIP 10K 5% 1/10W
R574 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S501 1-571-395-11 SWITCH, SLIDE (SYSTEM SELECT)
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC 10MHz
X503 1-767-519-11 VIBRATOR, CRYSTAL 27MHz
************************************************************
MISCELLANEOUS
**************
1 1-769-977-11 WIRE (FLAT TYPE) (13 CORE) (150 mm)
5 1-233-545-11 TUNER (FM/AM)
61 1-773-002-11 WIRE (FLAT TYPE) (15 CORE) (80 mm)
62 1-773-032-11 WIRE (FLAT TYPE) (15 CORE) (400 mm)
! 152 1-569-007-11 ADAPTOR, CONVERSION 2P (IA)
! 152 1-569-008-21 ADAPTOR, CONVERSION 2P (EA,MY,SP)
156 1-790-660-11 WIRE (FLAT TYPE) (23 CORE)
158 1-790-288-11 WIRE (FLAT TYPE) (13 CORE) (350 mm)
160 1-773-006-11 WIRE (FLAT TYPE) (15 CORE) (120 mm)
161 1-773-056-11 WIRE (FLAT TYPE) (17 CORE)
507 1-452-925-21 MAGNET ASSY
! 601 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
602 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
! CNP901 1-558-943-41 CORD, POWER (TH,IA)
! CNP901 1-575-651-21 CORD, POWER (EA,MY,SP)
HP101 A-2056-683-B DECK (A) ASSY, HEAD (230PWR2)(*NOTE)
HP101 A-2056-681-B DECK (A) ASSY, HEAD (230AWR2)(*NOTE)
HRPE101A-2056-684-B DECK (B) ASSY, HEAD (230PWR2)(*NOTE)
HRPE101A-2056-682-B DECK (B) ASSY, HEAD (230AWR2)(*NOTE)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
M901 1-698-792-11 FAN, DC
! T951 1-433-613-11 TRANSFORMER, POWER
************************************************************
*************
HARDWARE LIST
*************
#1 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#2 7-685-872-09 SCREW +BVTT 3 × 8 (S)
#3 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
#4 7-685-534-19 SCREW +BTP 2.6 × 8 TYPE2 N-S
#5 7-685-533-19 SCREW +BTP 2.6 × 6 TYPE2 N-S
#6 7-685-105-19 SCREW +P 2 × 8 TYPE2 NON-SLIT
#7 7-685-650-79 SCREW +BVTP 3 × 16 TYPE2 IT-3
#8 7-685-881-09 SCREW +BVTT 4 × 8 (S)
#9 7-685-853-04 SCREW +BVTT 2 × 6 (S)
#10 7-685-850-04 SCREW +BVTT 2 × 3 (S)
#11 7-685-851-04 SCREW +BVTT 2 × 4 (S)
#12 7-628-254-15 SCREW +PS 2.6 × 6
#13 7-628-254-50 SCREW +PS 2.6 × 16
*NOTE : Refer to page 73
VIDEO
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
