HCD-VX77/VX77J
44
44
Ref. No. Location
D701 E-1
IC701 E-1
IC711 B-5
7-19. PRINTED WIRING BOARD – DRIVER SECTION – • See page 23 for Circuit Boards Location.
• Semiconductor
Location
09
12
A
B
C
D
E
F
G
3456
(Page 34)
