68
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 9
ELECTRICAL PARTS LIST
A-4725-003-A BD BOARD, COMPLETE
*****************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C105 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C110 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C111 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C112 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C113 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-126-607-11 ELECT CHIP 47uF 20% 4V
C117 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C118 1-163-275-11 CERAMIC CHIP 0.001uF 5.00% 50V
C119 1-163-106-00 CERAMIC CHIP 36PF 5.00% 50V
C120 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C121 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C122 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C123 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C124 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C126 1-124-779-00 ELECT CHIP 10uF 20% 16V
C130 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C140 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C154 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C159 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C161 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C170 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C171 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C180 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C181 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C182 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C183 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C184 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C185 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C186 1-128-065-11 ELECT CHIP 68uF 20.00% 10V
C187 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P
< IC >
IC101 8-752-397-42 IC CXD3008Q
IC102 8-759-640-22 IC BA5982FM
IC103 8-752-085-51 IC CXA2568M-T6
IC104 8-759-325-67 IC TC7SH04F (TE85R)
IC104 8-759-398-25 IC TC7SH04F (TE85L)
< COIL >
L101 1-414-234-22 INDUCTOR CHIP 0uH
L102 1-410-377-31 INDUCTOR CHIP 4.7uH
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710-RTX
< RESISTOR >
R101 1-216-077-91 RES-CHIP 15K 5% 1/10W
R102 1-216-097-91 RES-CHIP 100K 5% 1/10W
R103 1-216-077-91 RES-CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-073-00 METAL CHIP 10K 5% 1/10W
R106 1-216-049-91 RES-CHIP 1K 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R109 1-216-121-91 RES-CHIP 1M 5% 1/10W
R110 1-216-295-91 SHORT 0
R112 1-216-025-91 RES-CHIP 100 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-91 RES-CHIP 100K 5% 1/10W
R125 1-216-033-00 METAL CHIP 220 5% 1/10W
R126 1-216-033-00 METAL CHIP 220 5% 1/10W
R127 1-216-033-00 METAL CHIP 220 5% 1/10W
R131 1-216-033-00 METAL CHIP 220 5% 1/10W
R135 1-216-295-91 SHORT 0
R136 1-216-295-91 SHORT 0
R137 1-216-295-91 SHORT 0
R138 1-216-295-91 SHORT 0
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R145 1-216-121-91 RES-CHIP 1M 5% 1/10W
R146 1-216-121-91 RES-CHIP 1M 5% 1/10W
BD
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
TH : Thai model
IA : Indonesian model
HK : Hong Kong model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
