Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R147 1-216-041-00 METAL CHIP 470 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-003-11 RES-CHIP 12 5% 1/10W
R150 1-216-073-00 METAL CHIP 10K 5% 1/10W
R154 1-216-025-91 RES-CHIP 100 5% 1/10W
R155 1-216-025-91 RES-CHIP 100 5% 1/10W
R156 1-216-025-91 RES-CHIP 100 5% 1/10W
R157 1-216-025-91 RES-CHIP 100 5% 1/10W
R158 1-216-073-00 METAL CHIP 10K 5% 1/10W
R159 1-216-089-91 RES-CHIP 47K 5% 1/10W
R161 1-216-295-91 SHORT 0
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-025-91 RES-CHIP 100 5% 1/10W
R172 1-216-025-91 RES-CHIP 100 5% 1/10W
R173 1-216-025-91 RES-CHIP 100 5% 1/10W
R175 1-216-025-91 RES-CHIP 100 5% 1/10W
R180 1-216-097-91 RES-CHIP 100K 5% 1/10W
R181 1-216-100-00 RES-CHIP 130K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-081-00 METAL CHIP 22K 5% 1/10W
R184 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R185 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R186 1-216-081-00 METAL CHIP 22K 5% 1/10W
R187 1-216-081-00 METAL CHIP 22K 5% 1/10W
R188 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R189 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R190 1-216-081-00 METAL CHIP 22K 5% 1/10W
R191 1-216-081-00 METAL CHIP 22K 5% 1/10W
R192 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R193 1-216-070-00 METAL CHIP 7.5K 5% 1/10W
R194 1-216-295-91 SHORT 0
R203 1-216-025-91 RES-CHIP 100 5% 1/10W
R204 1-216-025-91 RES-CHIP 100 5% 1/10W
R205 1-216-025-91 RES-CHIP 100 5% 1/10W
R206 1-216-295-91 SHORT 0
R210 1-216-295-91 SHORT 0
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT IN)
**************************************************************
A-4428-450-A CD SWITCH BOARD, COMPLETE
(VX77:MY,SP,EA,HK,IA,E)
**************************************
A-4428-978-A CD SWITCH BOARD, COMPLETE (VX77:TH)
*********************************
A-4473-045-A CD SWITCH BOARD, COMPLETE (VX77J)
*******************************
< DIODE >
D630 8-719-056-13 DIODE SML79423C-TP15 (DISC 1)
D631 8-719-056-13 DIODE SML79423C-TP15 (DISC 2)
D632 8-719-056-13 DIODE SML79423C-TP15 (DISC 3)
< TRANSISTOR >
Q630 8-729-422-57 TRANSISTOR BN1A4M-TP
Q631 8-729-422-57 TRANSISTOR BN1A4M-TP
Q632 8-729-422-57 TRANSISTOR BN1A4M-TP
Q633 8-729-422-57 TRANSISTOR BN1A4M-TP
Q634 8-729-422-57 TRANSISTOR BN1A4M-TP
Q635 8-729-422-57 TRANSISTOR BN1A4M-TP
< RESISTOR >
R685 1-249-417-11 CARBON 1K 5% 1/4W F
R686 1-249-418-11 CARBON 1.2K 5% 1/4W F
R687 1-249-420-11 CARBON 1.8K 5% 1/4W F
R688 1-249-422-11 CARBON 2.7K 5% 1/4W F
R689 1-247-843-11 CARBON 3.3K 5% 1/4W
R690 1-249-425-11 CARBON 4.7K 5% 1/4W F
R691 1-249-427-11 CARBON 6.8K 5% 1/4W F
R692 1-249-429-11 CARBON 10K 5% 1/4W
R750 1-249-406-11 CARBON 120 5% 1/4W F
R751 1-249-406-11 CARBON 120 5% 1/4W F
R752 1-249-406-11 CARBON 120 5% 1/4W F
R753 1-249-406-11 CARBON 120 5% 1/4W F
R754 1-249-406-11 CARBON 120 5% 1/4W F
R755 1-249-406-11 CARBON 120 5% 1/4W F
< SWITCH >
S642 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP)
S643 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S644 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S645 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S646 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE)
S647 1-762-875-21 SWITCH, KEYBOARD (PREV)
S648 1-762-875-21 SWITCH, KEYBOARD (NEXT)
S649 1-762-875-21 SWITCH, KEYBOARD (RETURN)
**************************************************************
1-675-912-11 DRIVER BOARD
***********
< CAPACITOR >
C702 1-126-964-51 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-336-11 PIN, CONNECTOR (LIGHT ANGLE) 10P
CN702 1-785-550-11 CONNECTOR, FFC/FPC 8P
< DIODE >
D701 8-719-109-66 DIODE MTZJ-T-77-3.3B
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
**************************************************************
1-676-220-11 HEAD (A) BOARD
************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
BD DRIVER HEAD (A)
CD SWITCH
