Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
IC301 8-759-652-80 IC HA12227F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-TE
IC304 8-759-656-83 IC NJM4580MD-TE
IC401 8-759-652-48 IC M30622MAA-A25FP
IC501 8-759-635-63 IC M51943BSL-TP
IC601 8-759-652-00 IC BA1450
IC651 8-759-288-54 IC LC72130
IC911 8-759-039-69 IC uPC7805AHF
IC921 8-759-088-08 IC uPC7812AHF
IC931 8-759-071-48 IC TA7807S
IC951 8-759-158-62 IC TA78057S
IC961 8-759-701-59 IC M5F7809L
< IFT >
IFT601 1-435-295-11 TRANSFORMER, IF
< JACK >
J101 1-793-987-11 JACK, PIN 2P (MD/VIDEO)
J102 1-774-819-11 JACK, PIN 2P (SURROUND SPEAKER)
< JUMPER RESISTOR >
JR1 1-216-296-91 SHORT 0
JR2 1-216-296-91 SHORT 0
JR3 1-216-296-91 SHORT 0
JR4 1-216-296-91 SHORT 0
JR6 1-216-296-91 SHORT 0
JR7 1-216-296-91 SHORT 0
JR8 1-216-295-91 SHORT 0
JR9 1-216-295-91 SHORT 0
JR13 1-216-296-91 SHORT 0
JR14 1-216-296-91 SHORT 0
JR15 1-216-296-91 SHORT 0
JR17 1-216-296-91 SHORT 0
JR18 1-216-295-91 SHORT 0
JR19 1-216-296-91 SHORT 0
JR23 1-216-296-91 SHORT 0
JR24 1-216-296-91 SHORT 0
JR25 1-216-296-91 SHORT 0
JR26 1-216-296-91 SHORT 0
JR27 1-216-296-91 SHORT 0
JR29 1-216-296-91 SHORT 0
JR31 1-216-295-91 SHORT 0
JR32 1-216-296-91 SHORT 0
JR33 1-216-296-91 SHORT 0
JR34 1-216-295-91 SHORT 0
JR35 1-216-296-91 SHORT 0
JR36 1-216-295-91 SHORT 0
JR37 1-216-296-91 SHORT 0
JR38 1-216-296-91 SHORT 0
JR39 1-216-296-91 SHORT 0
JR42 1-216-295-91 SHORT 0
JR44 1-216-296-91 SHORT 0
JR45 1-216-296-91 SHORT 0
JR51 1-216-296-91 SHORT 0
JR52 1-216-296-91 SHORT 0
JR53 1-216-296-91 SHORT 0
JR54 1-216-296-91 SHORT 0
JR140 1-216-296-91 SHORT 0
JR602 1-216-295-91 SHORT 0
JR603 1-216-296-91 SHORT 0
JR604 1-216-296-91 SHORT 0
JR605 1-216-296-91 SHORT 0
JR606 1-216-296-91 SHORT 0
JR607 1-216-295-91 SHORT 0
JR608 1-216-296-91 SHORT 0
JR611 1-216-296-91 SHORT 0
JR612 1-216-295-91 SHORT 0
JR615 1-216-295-91 SHORT 0
JR616 1-216-295-91 SHORT 0
JR619 1-216-295-91 SHORT 0
JR632 1-216-295-91 SHORT 0
JR634 1-216-295-91 SHORT 0
JR640 1-216-295-91 SHORT 0
JR922 1-216-295-91 SHORT 0
JR923 1-216-295-91 SHORT 0
JR924 1-216-295-91 SHORT 0
JR927 1-216-295-91 SHORT 0
JR928 1-216-295-91 SHORT 0
< COIL >
L201 1-414-189-31 INDUCTOR 100uH
L301 1-410-780-11 INDUCTOR 27MH
L302 1-414-193-41 INDUCTOR 220uH
L303 1-414-193-41 INDUCTOR 220uH
L351 1-410-780-11 INDUCTOR 27MH
L642 1-216-296-91 SHORT 0
< FILTER >
LPF601 1-234-458-11 FILTER, LOW PASS
LPF602 1-234-458-11 FILTER, LOW PASS
< TRANSISTOR >
Q101 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q102 8-729-144-85 TRANSISTOR 2SK1133-T1B
Q103 8-729-107-46 TRANSISTOR 2SC3624A-T1L15L16
Q141 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q151 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q152 8-729-144-85 TRANSISTOR 2SK1133-T1B
Q153 8-729-107-46 TRANSISTOR 2SC3624A-T1L15L16
Q301 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q302 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q303 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q304 8-729-113-69 TRANSISTOR FN1F4M-T1M32
Q305 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q391 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q392 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q393 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
Q394 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q395 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q396 8-729-116-57 TRANSISTOR 2SB1068TP-K
Q397 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q501 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q503 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q504 8-729-113-69 TRANSISTOR FN1F4M-T1M32
Q505 8-729-113-13 TRANSISTOR FA1A4M-T1L33
Q601 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q602 8-729-422-57 TRANSISTOR BN1A4M-TP
MAIN
