Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1-675-911-11 SENSOR BOARD
**************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTO INTERRUPTER >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (BU UP/DOWN)
**************************************************************
1-676-808-11 TRANS BOARD
*************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
0 C972 1-113-925-11 CERAMIC 0.01uF 20% 250V
(E, EA, MY, SP)
< CONNECTOR >
CN975 1-564-321-00 PIN, CONNECTOR 2P
* CN977 1-564-528-11 PLUG, CONNECTOR 13P
< FUSE >
0 F971 1-532-506-31 FUSE (T6.3AL/250)
0 F974 1-532-506-31 FUSE (T6.3AL/250)
0 F975 1-532-506-31 FUSE (T6.3AL/250)
0 F976 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250)
0 F977 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250)
< RESISTOR >
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< SWITCH >
0 S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
< TRANSFORMER >
0 T971 1-435-325-11 POWER TRANSFORMER
**************************************************************
A-4724-973-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C304 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C305 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C306 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C307 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C308 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C309 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C311 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C312 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C313 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C314 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C315 1-163-255-11 CERAMIC CHIP 150PF 5% 50V
C316 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C317 1-126-193-11 ELECT 1uF 20% 50V
C318 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C319 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C320 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C321 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C322 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C323 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C324 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C325 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C402 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C504 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C506 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C508 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C509 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C531 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C532 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C535 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C536 1-126-193-11 ELECT 1uF 20% 50V
C537 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C539 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C540 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C541 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C542 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C543 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C544 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C545 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C546 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C547 1-126-193-11 ELECT 1uF 20% 50V
C548 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C549 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C550 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C551 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C552 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C553 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C555 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C556 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C559 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C561 1-163-089-00 CERAMIC CHIP 6PF 50V
C563 1-165-319-11 CERAMIC CHIP 0.1uF 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
SENSOR TRANS VIDEO
