Sony HCD-VX88 - Page 82

82
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C564 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C565 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C566 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C568 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C569 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C570 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C571 1-128-065-11 ELECT CHIP 68uF 20% 10V
C573 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C574 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C576 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C577 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
CN501 1-779-343-21 CONNECTOR, FFC/FPC 23P
CN502 1-779-416-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< TRIMMER >
CT503 1-141-539-11 CAP, ADJ 10PF
< DIODE >
D501 8-719-422-12 DIODE UDZ-TE-17-3.9B
< IC >
IC101 8-759-701-40 IC NJM2100M (TE2)
IC301 8-759-530-30 IC TC74VHCU04FT (EL)
IC302 8-759-662-94 IC NJM2255M (TE2)
IC303 8-759-711-47 IC NJM2209M (TE2)
IC304 8-759-662-95 IC BA7665FS-E2
IC501 8-759-530-30 IC TC74VHCU04FT (EL)
IC502 8-759-663-01 IC M30620MCA-A34FP
IC504 8-759-530-30 IC TC74VHCU04FT (EL)
IC505 8-759-535-48 IC CL680T-D1
IC506 8-759-677-67 IC LC372100PM-K98-TLA
IC507 8-759-342-01 IC MSM514260C-60JS
IC509 8-759-535-62 IC PCM1727E-2/T2
< JACK >
J301 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J302 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< RESISTOR >
JW101 1-216-295-00 SHORT 0
JW201 1-216-295-00 SHORT 0
JW301 1-216-295-00 SHORT 0
JW302 1-216-025-00 RES-CHIP 100 5% 1/10W
JW304 1-216-295-00 SHORT 0
JW413 1-216-295-00 SHORT 0
JW504 1-216-295-00 SHORT 0
JW505 1-216-295-00 SHORT 0
JW513 1-216-295-00 SHORT 0
< COIL/SHORT >
L301 1-410-372-21 INDUCTOR CHIP 1.8uH
L302 1-410-372-21 INDUCTOR CHIP 1.8uH
L303 1-410-658-31 INDUCTOR CHIP 220uH
L501 1-216-296-00 SHORT 0
L502 1-216-296-00 SHORT 0
L504 1-410-375-11 INDUCTOR CHIP 3.3uH
L505 1-216-296-00 SHORT 0
L506 1-216-296-00 SHORT 0
L507 1-216-296-00 SHORT 0
L508 1-216-296-00 SHORT 0
L509 1-216-296-00 SHORT 0
L510 1-216-296-00 SHORT 0
L511 1-469-705-21 INDUCTOR 0uH
L512 1-469-705-21 INDUCTOR 0uH
L513 1-469-705-21 INDUCTOR 0uH
< TRANSISTOR >
Q501 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q502 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q531 8-729-140-75 TRANSISTOR 2SD999-T1-CLCK
< RESISTOR >
R101 1-216-073-00 METAL CHIP 10K 5% 1/10W
R102 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R103 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R201 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R203 1-208-441-61 RES-CHIP 1.5K 2% 1/10W
R302 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R303 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R306 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R308 1-216-073-00 METAL CHIP 10K 5% 1/10W
R309 1-216-073-00 METAL CHIP 10K 5% 1/10W
R310 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R311 1-216-029-00 METAL CHIP 150 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R313 1-216-073-00 METAL CHIP 10K 5% 1/10W
R314 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R315 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R316 1-216-022-00 METAL CHIP 75 5% 1/10W
R317 1-216-022-00 METAL CHIP 75 5% 1/10W
R318 1-216-295-00 SHORT 0
R319 1-216-624-11 METAL CHIP 75 0.5% 1/10W
R320 1-216-295-00 SHORT 0
R403 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R404 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R501 1-216-025-00 RES-CHIP 100 5% 1/10W
R502 1-216-025-00 RES-CHIP 100 5% 1/10W
R503 1-216-025-00 RES-CHIP 100 5% 1/10W
R504 1-216-025-00 RES-CHIP 100 5% 1/10W
R505 1-216-025-00 RES-CHIP 100 5% 1/10W
R506 1-216-025-00 RES-CHIP 100 5% 1/10W
R507 1-216-073-00 METAL CHIP 10K 5% 1/10W
R508 1-216-073-00 METAL CHIP 10K 5% 1/10W
R516 1-216-073-00 METAL CHIP 10K 5% 1/10W
R517 1-216-073-00 METAL CHIP 10K 5% 1/10W
R518 1-216-073-00 METAL CHIP 10K 5% 1/10W
R519 1-216-025-00 RES-CHIP 100 5% 1/10W
R520 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R523 1-216-013-00 METAL CHIP 33 5% 1/10W
R530 1-216-025-00 RES-CHIP 100 5% 1/10W
VIDEO
