Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R531 1-216-025-00 RES-CHIP 100 5% 1/10W
R532 1-216-295-00 SHORT 0
R533 1-216-295-00 SHORT 0
R534 1-216-073-00 METAL CHIP 10K 5% 1/10W
R535 1-216-073-00 METAL CHIP 10K 5% 1/10W
R536 1-216-033-00 METAL CHIP 220 5% 1/10W
R537 1-216-025-00 RES-CHIP 100 5% 1/10W
R538 1-216-073-00 METAL CHIP 10K 5% 1/10W
R539 1-216-295-00 SHORT 0
R540 1-216-295-00 SHORT 0
R542 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R543 1-216-685-11 METAL CHIP 27K 0.5% 1/10W
R544 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R545 1-216-025-00 RES-CHIP 100 5% 1/10W
R546 1-216-049-11 RES-CHIP 1K 5% 1/10W
R548 1-216-049-11 RES-CHIP 1K 5% 1/10W
R549 1-216-025-00 RES-CHIP 100 5% 1/10W
R550 1-216-025-00 RES-CHIP 100 5% 1/10W
R551 1-216-025-00 RES-CHIP 100 5% 1/10W
R552 1-216-025-00 RES-CHIP 100 5% 1/10W
R555 1-216-121-00 RES-CHIP 1M 5% 1/10W
R556 1-216-025-00 RES-CHIP 100 5% 1/10W
R557 1-216-025-00 RES-CHIP 100 5% 1/10W
R560 1-216-653-11 METAL CHIP 1.2K 0.5% 1/10W
R561 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R562 1-216-073-00 METAL CHIP 10K 5% 1/10W
R563 1-216-073-00 METAL CHIP 10K 5% 1/10W
R577 1-216-081-00 METAL CHIP 22K 5% 1/10W
R578 1-216-081-00 METAL CHIP 22K 5% 1/10W
R579 1-216-073-00 METAL CHIP 10K 5% 1/10W
R580 1-216-073-00 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X501 1-767-510-11 VIBRATOR, CERAMIC (10Mz)
X503 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
************************************************************
MISCELLANEOUS
**************
11 1-792-246-11 WIRE (FLAT TYPE) (23 CORE)
0 13 1-526-794-11 OUTLET, AC
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-690-589-31 WIRE (FLAT TYPE) (13 CORE)
0 108 1-575-653-11 CORD, POWER (E)
0 108 1-777-071-21 CORD, POWER (MY, SP)
0 108 1-777-071-51 CORD, POWER (EA, IA)
0 109 1-569-007-11 ADAPTOR, CONVERSION 2P (E)
0 109 1-569-008-21 ADAPTOR, CONVERSION 2P (EA, MY, SP, IA)
209 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
216 1-471-035-11 MAGNET ASSY
0 251 8-820-116-01 OPTICAL PICK-UP KSM-213DAP/Z-NP
252 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP901 X-4953-985-1 BLOCK (A) ASSY, HEAD (PB)
HRPE901X-4953-986-1 BLOCK (B) ASSY, HEAD (REC/PB/ERASE)
M721 A-4672-826-A MOTOR ASSY (TURN)
M901 X-3378-241-1 MOTOR ASSY (CAPSTAN/REEL)
M961 1-763-072-11 FAN, D. C.
0 T971 1-435-325-11 POWER TRANSFORMER
************************************************************
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
#7 7-623-921-01 WASHER 1.7, NYLON
#8 7-685-783-09 SCREW +PTT 2X6 (S)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
