HCD-VX880AV
27 27
IC514 (VSY)
IC503 4 (CD-LRCK)
(CD Play mode)
IC511 1 (CLK)
IC514 2-8, (YUVO-YUV7)
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed
in each block.)
For schematic diagrams.
Note:
All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
All resistors are in and
1
/
4
W or less unless otherwise
specified.
¢
: internal component.
2 : nonflammable resistor.
1 : fusible resistor.
C : panel designation.
For printed wiring boards.
Note:
X : parts extracted from the component side.
Y : parts extracted from the conductor side.
®
: Through hole.
b : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
U : B+ Line.
V : B– Line.
H : adjustment for repair.
Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
Voltages are taken with a VOM (Input impedance 10 M).
Voltage variations may be noted due to normal produc-
tion tolerances.
Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
Circled numbers refer to waveforms.
Signal path.
F : FM
g : VIDEO/MD
E : PB (DECK A)
d : PB (DECK B)
G : REC (DECK B)
m : CHROMA
n : Y
o : VIDEO
J : CD
c : digital out
IC101 @∞ MDP
1
2
3
4
WAVEFORMS
– CD SECTION –
IC101 RFAC
IC101 TE
IC101 FE
Indication of transistor
1.3Vp-p
Caution:
Pattern face side: Parts on the pattern face side seen from the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
APPROX 500mVp-p
2.5V
APPROX 200mVp-p
2.5V
2.6Vp-p
7.5µsec
– PANEL (1/2) SECTION –
1
2
IC501 XC-OUT
IC501 X-OUT
– MAIN (3/4) SECTION –
IC601 &™ X OUT
1
16MHz
5.5Vp-p
32.768kHz
5.2Vp-p
12.5MHz
3.4Vp-p
1
2
3
IC503 8 (CD-LRCK)
IC503 (CD-BCK)
4
5
6
7
8
9
IC511 !∞!§!¶!• (CD Stop mode)
IC511 8 (OSC IN)
0
IC505 (XOUT)
IC502 !∞ (XIN)
IC514 @• (HSY)
VIDEO SECTION –
4.8Vp-p
0.47µsec
!™
J301 4 (YOUT)
J301 3 (COUT)
!∞
IC509 4 (MCKO)
IC509 (384FSO)
IC509 (768FSO)
4.8Vp-p
0.47µsec
4.8Vp-p
12.5µsec
4.0Vp-p
10MHz
3.0Vp-p
10MHz
7.5µsec
4.8Vp-p
4.8Vp-p
45µsec
5.0Vp-p
H
3.5Vp-p
36nsec
2.0Vp-p
H
H
1.8Vp-p
4.6Vp-p
37µsec
4.8Vp-p
59µsec
4.2Vp-p
30nsec
Note:
The components iden-
tified by mark ! or dot-
ted line with mark !
are critical for safety.
Replace only with part
number specified.
Note:
C
These are omitted
EB
Q
C
These are omitted
EB
