79
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
D932 8-719-988-61 DIODE 1SS355TE-17
D3001 8-719-200-82 DIODE 11ES2-TB5
< IC >
IC101 8-759-571-54 IC M62493FP
IC201 8-759-571-51 IC M62464FP
IC301 8-759-495-26 IC HA12215F
IC421 8-749-923-04 IC TOTX178A
IC501 8-759-639-96 IC M30622MA-A16FP
IC502 8-759-635-63 IC M51943BSL-TP
IC901 8-759-231-53 IC M5F7805L
IC902 8-759-604-86 IC M5F7807L
IC903 8-759-604-32 IC M5F7810L
IC904 8-759-701-79 IC NJM7812FA
IC905 8-759-231-53 IC M5F7805L
< JACK >
J101 1-774-411-11 JACK, PIN 6P (VIDEO (AUDIO)/MD IN, OUT)
J102 1-779-599-11 JACK, PIN 6P (DVD INPUT)
J191 1-774-785-11 JACK, PIN 1P (WOOFER OUT)
< COIL >
L421 1-410-482-31 INDUCTOR 100uH
L501 1-410-470-11 INDUCTOR 10uH
< TRANSISTOR >
Q111 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q112 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q113 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q114 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q161 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q162 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q163 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q164 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q191 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q281 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q282 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q291 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q371 8-729-118-00 TRANSISTOR 2SB1116-TP-LK
Q372 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q373 8-729-118-00 TRANSISTOR 2SB1116-TP-LK
Q374 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q375 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q376 8-729-116-59 TRANSISTOR 2SB1068TP
Q377 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q378 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q379 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q380 8-729-116-59 TRANSISTOR 2SB1068TP
Q381 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q382 8-729-029-21 TRANSISTOR DTA114ESA-TP
Q383 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q411 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q421 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q431 8-729-111-29 TRANSISTOR 2SD1616-TP-LK
Q432 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q461 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q501 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q502 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q503 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q901 8-729-209-15 TRANSISTOR 2SD2012
Q902 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q903 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q904 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q905 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q906 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-049-79 TRANSISTOR RTIP137S-TP
Q907 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q910 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q913 8-729-040-20 TRANSISTOR RT1P137L-TP
Q914 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q915 8-729-141-83 TRANSISTOR 2SB1375
Q916 8-729-900-36 TRANSISTOR BA1F4M-TP
Q951 8-729-141-83 TRANSISTOR 2SB1375
Q952 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q953 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
< RESISTOR >
R101 1-216-049-91 RES,CHIP 1K 5% 1/10W
R102 1-216-049-91 RES,CHIP 1K 5% 1/10W
R103 1-216-049-91 RES,CHIP 1K 5% 1/10W
R111 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
R113 1-216-295-91 SHORT 0
R114 1-216-113-00 METAL CHIP 470K 5% 1/10W
R115 1-216-112-00 RES,CHIP 430K 5% 1/10W
R116 1-216-106-00 METAL CHIP 240K 5% 1/10W
R117 1-216-045-00 METAL CHIP 680 5% 1/10W
R118 1-216-081-00 METAL CHIP 22K 5% 1/10W
R119 1-216-105-91 RES,CHIP 220K 5% 1/10W
R120 1-216-073-00 METAL CHIP 10K 5% 1/10W
R121 1-216-089-91 RES,CHIP 47K 5% 1/10W
R122 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R123 1-216-097-91 RES,CHIP 100K 5% 1/10W
R124 1-216-073-00 METAL CHIP 10K 5% 1/10W
R125 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R126 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R128 1-216-121-91 RES,CHIP 1M 5% 1/10W
R131 1-216-025-91 RES,CHIP 100 5% 1/10W
R132 1-216-025-91 RES,CHIP 100 5% 1/10W
R133 1-216-025-91 RES,CHIP 100 5% 1/10W
R141 1-216-081-00 METAL CHIP 22K 5% 1/10W
R142 1-216-081-00 METAL CHIP 22K 5% 1/10W
R143 1-216-049-91 RES,CHIP 1K 5% 1/10W
R144 1-216-097-91 RES,CHIP 100K 5% 1/10W
R145 1-216-121-91 RES,CHIP 1M 5% 1/10W
R151 1-216-049-91 RES,CHIP 1K 5% 1/10W
R152 1-216-049-91 RES,CHIP 1K 5% 1/10W
R153 1-216-049-91 RES,CHIP 1K 5% 1/10W
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-073-00 METAL CHIP 10K 5% 1/10W
R163 1-216-295-91 SHORT 0
R164 1-216-113-00 METAL CHIP 470K 5% 1/10W
R165 1-216-112-00 RES,CHIP 430K 5% 1/10W
R166 1-216-106-00 METAL CHIP 240K 5% 1/10W
R167 1-216-045-00 METAL CHIP 680 5% 1/10W
To Next Page
